Fnirsi-1013d 7 Inch Digital Tablet Oscilloscope 100mhz Band Width Tft Lcd Screen

US $175.18

Shenzhen, China
Jul 23rd

Open on mobile:
QR code

Product Description FNIRSI 1013D 7 inch Digital Tablet Oscilloscope 2CH 100MHz Bandwidth 1GS Sampling Rate Descriptions: FNIRSI-1013D is a full-featured, highly practical, cost-effective dual-channel flat-panel oscilloscope launched by FNIRSI for the maintenance and R & D industry.This oscilloscope has a real-time sampling rate of 1GSa / s and an analog bandwidth of 100MHz * 2 . 1.With complete trigger function (single / normal / automatic), it can be used freely for periodic analog signals or non-periodic digital signals; 2.The built-in high-voltage protection module can tolerate a continuous voltage of up to 400V. Oscilloscope burnout accident caused by the probe being turned to the 10X position. Large time base scroll mode can monitor slow level changes; 3.Equipped with highly efficient one-key AUTO, which can display the measured waveform without tedious adjustments; 4.The display is equipped with a 7-inch 800 * 480 resolution high-definition LCD LCD screen, and the operation method is capacitor Screen touch + gesture operation, extremely convenient; 5.Cursor measurement function, you do not need to read the background scale unit and quantity when manually reading the amplitude and frequency parameters, and you can directly get the peak, peak and frequency without conversion; 6.Extremely convenient screenshot And waveform storage function, built-in 1GB storage space, can store up to 1000 screenshots + 1000 sets of waveform data, the storage process is simple and fast, save the current waveform anytime, anywhere with a single touch, no cumbersome prompts and choices, keep calm The current data is saved in the place, which is very convenient; 7.The powerful waveform picture manager supports thumbnail browsing, viewing, detailed viewing, page turning, deletion and waveform zooming in, zooming out, moving, etc., to facilitate secondary analysis. The fuselage is equipped with a USB interface, which can be connected to a computer to share its screenshots with the computer, which is convenient for secondary analysis; 8.Lissajous figures graphic display function can be used to determine the amplitude, frequency, and phase contrast of two groups of signals; Analysis of the harmonic components of the signal; built-in 6000mah high-quality lithium battery, which can last for 4 hours on a full charge, and can be used while charging like a notebook Features: Intelligent anti-burn1X Can withstand up to 400V withstand voltage. 100MHz analog bandwidth @ 1GSa/s sapling rate1X = 5MHz10X = 100MHz. Fully fit 7 inch 800 * 480 resolution color TFT LCD display with bright colors and high contrast. Capacitive touch screen, the same as the touch mode of modern mobile ipad, is not a resistive touch screen with ancient nail operation. High measurement voltage range, 1X can measure 0 ~ 40 V, 10X can measure 0 ~ 400V100X can measure 0 ~ 4000V. Up to 12 parameters measurementVPPVPVmaxVminVavgVrmsFrequentDuty+Duty-Time+Time-Period. Cursor measurement function, it is convenient to manually measure the period and frequency and voltage. Complete triggering function (single, normal, automatic). At any time, the waveform display (pause function) is frozen. Equipped with high efficiency One-button AUTO. One-button waveform storage and screenshot. Built-in 1GB storage space, can store up to 1000 screenshots + 1000 sets of waveform data. Powerful waveform picture manager supports thumbnail browsing, viewing, detailed viewing, page turning, deletion and waveform zooming in, zooming out, moving, etc. Equipped with a USB interface, which can be connected to a computer to share its screenshots with the computer, which is convenient for secondary analysis. Lissajous figures graphic display function can be used to determine the amplitude, frequency, and phase contrast of two groups of signals. FFT display function, can analyze the spectral characteristics of the signal. Built in 6000mAh rechargeable lithium batteryFully charged for 4 hours of continuous use at the highest screen brightness. Memory compression technology, waveform refresh screen does not flicker. Screen brightness adjustment. Background grid brightness adjustment. Ultra thin, easy to carry. Specifications: Analog band width: 100MHz * 2 Number of channels: 2 channels Maximum real time sampling rate: 1GSa/s Vertical sensitivity: 50 mV/div ~ 500 V/div Horizontal time base range: 50S/div ~ 10nS/div Maximum test voltage: 40 V (1X probe), 400 V (10X probe) Storage depth: 240Kbit Input resistance: 1M ADC precision: 8bits Coupling mode: AC/DC Trigger mode: Single, Normal, Auto Trigger edge: Rising edge/Falling edge External trigger voltage 0 – 40 V Display: 7 inch - 800*480 Operating: Capacitive touch screen + gesture Extension portsUSB picture export Power supply: 6000 mAh lithium battery Size: 184mm x 124mm x 50mm Total weight:650g Package includes: 1 x FNIRSI-1013D oscilloscope host 2 x Matching 100MHz probe1X and 10X 1 x 5V2A ChargerInclude USB data line 1 x User manual (English) Payment Delivery details Return About us Contact us Payment We accept Payment via PayPal only. If you do not have a PayPal Account you can still pay with your Credit / Debit Card, but this will be through PayPal ONLY. VAT and TAX is not included, please not. Delivery details Will ship order within 1 working days after get your payment. We do NOT accept any Email/Message note before or after you place orders. If item price is over $15, we'll ship with tracking number. Or it depends(except US). Shipping to US,AU,UK and CA takes about 7-15 working days for delivery normally. Standard shipping to other countries is about 7-25 working days. If remote countries, like Peru, Chile,Brazil and so on, it takes about 25-45 working days for delivery normally.Economy shipping takes about 10 working days more than standard shipping. shipping is out of control. Sometime shipping may take longer time. Hope you can wait some more days. If item did not arrive before Estimated date, pls contact us. We can refund or resend first, don't worry. Don't leave a negative feedback before contact us. Thank you very much. Return We understand that not every purchase is a good one for every custome Please note that we only accept returns within 30 days after delivery. If the item is defective/DOA (Dead on Arrival) we must be notified within 2 days of arrival, and a refund in full will be granted after item is sent back. Returns after 30 days will not be accepted. Please allow up to 3 business days for your item to be inspected and your return to be be processed. About us We will make every effort to make your shopping the most pleasant and wonderful! Any question feel free to contact us! Please do not leave negative and neutral rating , if you have any questions , please contact us . We will do best to solve it. Contact us We'll reply your message within 24 hours on working day because of jet lag. If Weekends or holidays, we'll reply within 48 hours. Will do best to solve problem. Please trust us. On Dec-22-20 at 23:18:44 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	FNIRSI
Storage depth	240Kbit
MPN	WU0797MG-53
ADC precision	8bits
Number of Channels	2 channels
Trigger edge	Rising edge/Falling edge
Vertical sensitivity	50 mV/div ~ 500 V/div
Display	7 inch - 800*480
Maximum test voltage	40V(1Xprobe), 400V(10Xprobe)
Extension ports	USB picture export
Input resistance	1M
Size	184mm x 124mm x 50mm
Coupling mode	AC/DC
Trigger mode	Single, Normal, Auto
Country/Region of Manufacture	China
External trigger voltage	0 – 40 V
Analog band width	100MHz * 2
Operating	Capacitive touch screen, gesture
Maximum real time sampling rate	1GSa/s
Power supply	6000 mAh lithium battery
Horizontal time base range	50S/div ~ 10nS/div
Total weight	650g
UPC	Does not apply
