Fnirsi Handheld Pocket Oscilloscope 5ms/s Sampling Rate For Vehicle Maintenance

US $45.32

Shenzhen, China
Jul 11th

Open on mobile:
QR code

FNIRSI Handheld Pocket Oscilloscope 5MS/S Sampling Rate For Vehicle Maintenance Description FNIRSI DSO188 Handheld Mini Pocket Portable Ultra-small Digital Oscilloscope 1MHz Bandwidth 5MS/S Sampling Rate High Quality Descriptions: DSO188 is a super small digital oscilloscope with 5MS/s sampling rate and 1MHz bandwidth is designed for electronic enthusiasts and circuit R & D maintenance personnel. 1MHz bandwidth can be used for an amplifier, oscillator, automatic control system, DC/DC, inverter, switching power supply and so on. Whether DIY or scientific research education, vehicle maintenance, household appliances maintenance and so on are all good choices. Features: 1:Memory compression technology, waveform refresh screen does not flicker 2:1.8-inch color display screen 3:1MHz analog bandwidth and 5MS/s sampling rate 4:High measurement voltage range, 1X can measure 0 ~ 40 V, 10X can measure 40 ~ 800V 5:Frequency can be displayed, Vmax, Vmin, Duty, Vrms, Vpp 6:At any time, the waveform display (pause function) is frozen 7:Battery/USB power supply, built-in 250mAh battery and intelligent charge management 8:Ultra small volume, easy to carry Specifications: Analog band width: 1MHz Maximum real time sampling rate: 5MS/s Vertical sensitivity: 50 mV/div ~ 200 V/div Horizontal time base range: 100mS/div ~ 2uS/div Maximum input voltage: 40 V (1X probe), 600 V (10X probe) Storage depth: 40KB Input resistance: 1M ADC accuracy: 12bits Coupling mode: AC/DC Trigger mode: Auto Trigger edge: Ascending/descending edge External trigger voltage: 0 - 40 V Display: TFT color display Power supply: 300 mAh lithium batteryIt can work continuously for 2.5 hours Weight: Approx.86g/3oz Package list: 1 x FNIRSI DSO188 oscilloscope host 1 x Oscilloscope probe 1 x BNC turn MCX switch head 1 x Micro USB data cable 1 x User manual (English)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	FNIRSI
Country/Region of Manufacture	China
MPN	WU0923-42
Analog band width	1MHz
Maximum real time sampling rate	5MS/s
Vertical sensitivity	50 mV/div ~ 200 V/div
Horizontal time base range	100mS/div ~ 2uS/div
Maximum input voltage	40 V (1X probe), 600 V (10X probe)
Storage depth	40KB
Input resistance	1M
ADC accuracy	12bits
Coupling mode	AC/DC
Trigger mode	Auto
Trigger edge	Ascending/descending edge
External trigger voltage	0 - 40 V
Display	TFT color display
Power supply	300 mAh lithium battery
work time	2.5 hours
UPC	Does not apply
