Fowler 52-664-009 Pocket Optical Comparators 10x Magnification

US $146.79

Miami, FL, United States
Jul 12th

Open on mobile:
QR code

Fowler 52-664-009 Pocket Optical Comparators, 10X Magnification Optical comparator with 10X magnification and set of nine reticles for measuring line thickness, screw threads, angles, radii, circles, degrees, and length Glass lens provides high-resolution images Scales are photo-etched onto a glass reticle for accuracy and distortion-free viewing Set of nine reticles includes thickness and hole reticle; line thickness reticle; circle, square, and angle reticle; metric screw thread reticle; inch screw thread reticle; angle reticle; inch/metric linear scale reticle; metric reticle; and a circle, angle, and concentric circle reticle A dioptric number and a magnification number are not the same thing. Diopter strength represents a specific magnification power (X). For example, a 5-diopter provides 2.5X magnification (at a distance of 8") The Fowler 52-664-009 optical comparator has 10X magnification and a set of nine reticles for measuring line thickness, screw threads, angles, radii, circles, degrees, and length. A glass lens provides high-resolution images. Scales are photo-etched onto glass reticles for accuracy and distortion-free viewing. The set of nine reticles includes one each Fowler 52-661-001 thickness and hole reticle; Fowler 52-661-002 line thickness reticle; Fowler 52-661-003 circle, square, and angle reticle; Fowler 52-661-004 metric thread reticle; Fowler 52-661-005 inch thread reticle; Fowler 52-661-006 angle reticle; Fowler 52-661-007 inch/metric scale reticle; Fowler 52-661-008 linear scale reticle; and Fowler 52-661-009 circle, angle, and concentric circle reticle. Each reticle includes a protective plastic case and the set includes a fitted plastic case. Specifications 52-661-001 Thickness and hole reticle 52-661-002 Line thickness from 0.02 to 0.16mm 52-661-003 Degrees from 0 to 90°, with 1° and 5° divisions 52-661-004 Metric screw threads 0.25, 0.3, 0.35, 0.4, 0.6, 0.75, 0.9, and 1mm 52-661-005 UNF screw threads 4, 7, 8, 9, 10, 12, 14, 16, and 25 TPI 52-661-006 Angles: 0, 8°, 30°, 45°, 50°, 55°, 60°, 90°, and 117° Degrees: 180° to 270° in 1° divisions 52-661-007 Linear inch/metric scale with 0 to 0.6"/0 to 15mm measuring range and 0.005"/0.05mm graduation interval 52-661-008 Linear metric scale with 0 to 20mm measuring range and 0.01mm divisions 52-661-009 Degrees: 0 to 90° (one 10° degree area marked in 1° intervals) Circles: 0.1 to 1.0mm diameter and 0.005 to 1/16" diameter Inch scale: 0 to 0.5" (0.005" divisions); 0 to 1/8" (1/64" divisions)Linear metric scale: -10 to 0 to 10mm with 0.1mm divisions Angles: 29°, 50°, 55°, and 118° Radius: 0 to 90° (0.1 and 0.5mm divisions) Diopter (D) is a technical term for the measurement of the light curvature and thickness of a lens. A dioptric number and a magnification number are not the same thing. Diopter strength represents a specific magnification power (X). For example, a 5-diopter provides 2.5X magnification (at a distance of 8"). The higher the diopter, the more magnification a lens can provide. As magnification increases, distance to the object (focal length), and field of view (diameter, or narrowness of view) decrease. Magnifiers and prescription eyeglasses have a diopter value, such as 1.5 or 2. The dioptric strength of an accessory lens, such as prescription eyeglasses or an eye loupe, must be added to the dioptric strength of the magnifier to calculate total magnification. Magnifiers are devices used to enlarge the visual appearance of an object or image. Magnifiers come in a variety of styles such as hand-held, headband, standing, clip-on, eye loupe, and those that hang in a necklace form, or fit in a trouser pocket. Magnifiers are commonly made of plastic or glass. They can have one or more lenses with varying magnification abilities, and can have a binocular configuration with a single lens, or two separate lenses. They are sometimes used with LED or fluorescent light sources to help control viewing capabilities. Magnifier ability is often expressed as magnification at a specific length. For example, 1.75X at 14" means that when a magnifier is held at 14" from a viewer's eyes, the object will be magnified 1.75 times (X) its actual size. As magnification increases, viewing areas and focal length decrease. Magnifiers sometimes have a diopter number, expressed as + or - D, which is a measurement of strength (or power) of the lens. Some magnifiers are marked with a dioptric number on the lens. A high diopter number has a higher magnification than a low diopter number. Aspheric magnifiers, unlike spheric magnifiers, produce a sharp image to the edge of the lens for less distortion. Magnifiers are widely used in jewelry inspection and fabrication, watch-making, needlework, artwork, reading, print inspection, and stamp-collecting. The Fred V. Fowler Company manuf Shipping We offer FREE shipping on all orders! We ship within Three business days of payment, usually sooner. We use a selection of shipping services such as UPS, FedEx, USPS etc. We only ship to the lower 48 states, no APO/FPO addresses or PO Boxes allowed. Local pickups and combined shipping options are not provided at this time. Return You can return a product for up to 30 days from the date you purchased it. Any product you return must be in the same condition you received it and in the original packaging. Please keep the receipt. Payment We accept payment by any of the following methods: PayPal Please pay as soon as possible, as that will allow us to post your item to you sooner! Feedback Customer satisfaction is very important to us. If you have any problem with your order, please contact us and we will do our best to make you satisfied. Contact Us If you have any queries, please contact us via ebay. We usually respond within 24 hours on weekdays. Please visit our eBay store to check out other items for sale! Thank you for shopping at our store.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Size	10X Magnification
Model	Does not apply
MPN	Does not apply
Brand	Fowler
UPC	646795124943
ISBN	0646795124943
EAN	Does not apply
