Fowler Coax-2d 2 Dimensional Coaxial Indicator Set 52-710-025 6.87" Length 0....

US $341.42

NY, United States
Aug 6th

Open on mobile:
QR code

Fowler COAX-2D 2 Dimensional Coaxial Indicator Set, 52-710-025, 6.87" Length, 0.250" Maximum Measuring, 0.0005" Graduation Interval The Fowler 52-710-025 coaxial indicator has a 1.6" diameter continuous dial, a 0.250" axis offset measuring range, 0.0005" graduations, an accuracy of + or - 0.0002" of true center, and can be used at any angle at speeds up to 800 RPMs for accurate centering and positioning of components in most machining applications. The 0-50 continuous dial remains stationary during spindle rotation and has a total measuring range of 0.250" with 0.0005" graduations. Three internal and three external feelers and a center point feeler have a 1/8" ball diameter and a locating accuracy of + or - 0.0002" of true center. The internal feelers have a measuring capacity of 5/32 to 12". The external feelers have a measuring capacity of 0 to 12". This product has 1 year full warranty offered by Fowler High Precision, an American company. If you experience any problem contact Fowler directly for warranty claims. The set includes a coaxial indicator, three internal feelers, three external indicators, a center point feeler, a restraining arm, and a fitted storage case. Dial readings with three digits, 0-10-0 for example, signify that the indicator has a balanced dial. Dial readings with two digits, 0-100 for example, indicate the dial has a continuous dial. Balanced dials are used for reading the difference from a specific surface reference point. Continuous dials are used for direct readings and usually have a larger measurement range than balanced dials. Specifications Dial face type and diameter 1.6" diameter face Dial reading and graduations Continuous 0-50 with 0.0005" graduations Measuring range 0.250" axis offset Speed Up to 800 RPMs Internal measuring capacity 5/32 to 12" External measuring capacity 0 to 12" Centering accuracy + or - 0.0002" of true center Feeler ball diameter 1/8" Test indicator gauges, also called gages, are precision instruments that measure short linear distances. They are commonly used for detecting deviations from tolerance limits, such as small variations in flatness or height of an inspected workpiece, and permit measurement in narrow grooves or small bores. A test indicator gauge consists of a ball-tipped contact point on a levered arm, also called a measuring insert, which pivots from a hinge point. The reading indicates the degree of angular displacement of the arm. Test indicator gauges are commonly used in manufacturing, machining, and mechanical engineering. Standard test indicators measure the displacement of the arm perpendicular to the axis of the indicator. Dial and electronic indicators are very similar to test indicators, except that the axis of measurement is parallel to the axis of the indicator. Test indicators can be analog, with a mechanical dial, or electronic, with a digital display. Some electronic models transfer the data electronically to a computer for recording and potential manipulation. Fowler, an American company, manufactures inspection and measurement instruments such as electronic indicators, calipers, bore gages, and digital scales. The company, founded in 1946, is headquartered in Newton, MA. What’s in the Box? · Coaxial indicator · Internal feelers (3) · External feelers (3) · Center point feeler · Restraining arm · Fitted storage case 1 year warranty offered by Fowler High Precision Two-dimensional coaxial indicator can be used at any angle for accurate centering and positioning of components in most machining applications 1.6" diameter continuous dial has a 0-50 dial reading, 0.250" offset axis measuring range, and 0.0005" graduations for taking direct readings Three internal and three external feelers and a center point feeler have 1/8" ball diameter, a locating accuracy of + or - 0.0002" of true center and provide a wide measuring capacity of 0-12" (0-300mm), face remains stationary during spindle rotation up to 800 RPMs Set includes coaxial indicator, three internal feelers, three external feelers, center point feeler, restraining arm, and fitted case SHIPPING We offer FREE shipping on all orders! We ship within Three business days of payment, usually sooner We use a selection of shipping services such as UPS, FedEx, USPS etc We only ship to the lower 48 states, no APO/FPO addresses or PO Boxes allowed Local pickups and combined shipping options are not provided at this time PAYMENT We accept payment by PayPal only (Can accept all kind of credit cards) Before buying, please make sure your PayPal and eBay address is correct. If not, please correct it before payment. We have confidence in our products, but if you are not fully satisfied please contact us within 30 days of purchase and you will get full refund of your money. Return the product in the same condition you received it. Please note - return shipping will be paid by the buyer.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does not apply
Brand	Fowler
Model	Does not apply
UPC	646795165984
ISBN	0646795165984
EAN	Does not apply
