Home About Us Feedback Newsletter Store Categories Fowler Full Warranty COAX-2D 2 Dimensional Coaxial Indicator Set, 52-710-025, 6.87" Length, 0.250" Maximum Measuring, 0.0005" Graduation Interval Arts Crafts & Sewing Baby Beauty Camera & Photo Electronics Home & Kitchen Home Improvement Kitchen & Dining Office Products Toys & Games Item Description The Fowler 52-710-025 coaxial indicator has a 1.6" diameter continuous dial, a 0.250" axis offset measuring range, 0.0005" graduations, an accuracy of + or - 0.0002" of true center, and can be used at any angle at speeds up to 800 RPMs for accurate centering and positioning of components in most machining applications. The 0-50 continuous dial remains stationary during spindle rotation and has a total measuring range of 0.250" with 0.0005" graduations. Three internal and three external feelers and a center point feeler have a 1/8" ball diameter and a locating accuracy of + or - 0.0002" of true center. The internal feelers have a measuring capacity of 5/32 to 12". The external feelers have a measuring capacity of 0 to 12". This product has 1 year full warranty offered by Fowler High Precision, an American company. If you experience any problem contact Fowler directly for warranty claims. The set includes a coaxial indicator, three internal feelers, three external indicators, a center point feeler, a restraining arm, and a fitted storage case. Dial readings with three digits, 0-10-0 for example, signify that the indicator has a balanced dial. Dial readings with two digits, 0-100 for example, indicate the dial has a continuous dial. Balanced dials are used for reading the difference from a specific surface reference point. Continuous dials are used for direct readings and usually have a larger measurement range than balanced dials. Specifications Dial face type and diameter 1.6" diameter face Dial reading and graduations Continuous 0-50 with 0.0005" graduations Measuring range 0.250" axis offset Speed Up to 800 RPMs Internal measuring capacity 5/32 to 12" External measuring capacity 0 to 12" Centering accuracy + or - 0.0002" of true center Feeler ball diameter 1/8" Test indicator gauges, also called gages, are precision instruments that measure short linear distances. They are commonly used for detecting deviations from tolerance limits, such as small variations in flatness or height of an inspected workpiece, and permit measurement in narrow grooves or small bores. A test indicator gauge consists of a ball-tipped contact point on a levered arm, also called a measuring insert, which pivots from a hinge point. The reading indicates the degree of angular displacement of the arm. Test indicator gauges are commonly used in manufacturing, machining, and mechanical engineering. Standard test indicators measure the displacement of the arm perpendicular to the axis of the indicator. Dial and electronic indicators are very similar to test indicators, except that the axis of measurement is parallel to the axis of the indicator. Test indicators can be analog, with a mechanical dial, or electronic, with a digital display. Some electronic models transfer the data electronically to a computer for recording and potential manipulation. Fowler, an American company, manufactures inspection and measurement instruments such as electronic indicators, calipers, bore gages, and digital scales. The company, founded in 1946, is headquartered in Newton, MA. What’s in the Box? · Coaxial indicator · Internal feelers (3) · External feelers (3) · Center point feeler · Restraining arm · Fitted storage case Main Features 1 year warranty offered by Fowler High Precision Two-dimensional coaxial indicator can be used at any angle for accurate centering and positioning of components in most machining applications 1.6" diameter continuous dial has a 0-50 dial reading, 0.250" offset axis measuring range, and 0.0005" graduations for taking direct readings Three internal and three external feelers and a center point feeler have 1/8" ball diameter, a locating accuracy of + or - 0.0002" of true center and provide a wide measuring capacity of 0-12" (0-300mm), face remains stationary during spindle rotation up to 800 RPMs Set includes coaxial indicator, three internal feelers, three external feelers, center point feeler, restraining arm, and fitted case Specifications Manufacturer: Fred V. Fowler Company, Inc. Shipping Weight: 225 Product Dimensions: Width: 5.30 Length: 8.60 Height: 3.00 Tips For Buyers It is very important that you are happy as a customer of ours so we please ask that you consider the following… Make sure to review all information in the description area. Review our seller policies before buying. Do not only view the photo, as the description is the main product spec. We can only ship to the address that is registered on the Ebay account, so please make sure that is correct before purchasing. SHIPPING DETAILS All of our item purchased will ship to each location based on shipping destination and weight. We strive to ship each item within a 24-hour time period once we have received and processed your payment. Every item will ship from a United States based location and the shipping method may vary, but is intended to be the best option for the item. All shipping costs are at no expense and covered by us. Our main goal is to get you your item as quickly as possible to ensure the highest level of satisfaction. As always, customer service is our pleasure. ABOUT US We love taking care of our customer’s retail needs. For years, we ran local retail and grew into the Ebay business to reach our national market. It is our joy to run the best online store for our customers. As a business, we strive to make sure that we can get you your items as quickly as possible. Pricing is always set to be as low as possible so you can enjoy your purchase at the greatest discount. In any event, if you wish to communicate with us, we are here to take care of you and communicate back within a 24-hour time frame. If you are looking for something different or a variation of a product, send us a message and we can check on it for you. 30 DAYS RETURN & REFUND POLICY We provide our customers with a 30 day exchange or return policy. If you would like a refund or an exchange, please contact us and we are happy to help you. The cost of the postage will be covered by the purchaser for a return of defective parts. If you are looking for a return of a defective item, we only allow for “factory defects” as the returned item reason. Please ensure that you return your item within the 30 day allowance from the date in which you purchased. When we get the item, we request that you provide 7 business days for the completion of return processing. Your return must have all parts and accessories included in your shipment and in the same condition it was received. As always, our mission is to take the best care of our customers, so please make sure if there is any problem to contact us for the quickest resolution possible that is equally fair. OUR GUARANTEE Our guarantee of item happiness is our biggest concern. We strive for 100% guarantee that you will be satisfied as our valued customer. If any issue arises that you need help on, we ask that you communicate by message or phone inside of 7 days of receiving your item so we can help to quickly resolve your issue. We have the utmost of gratitude to you, our precious customer, and will strive for the best business practices in every product purchase. It is very important to make sure our reputation as a seller remains intact, as you can see by our wonderful feedback from our customers. If you have any problems with your purchased item, please communicate with us before leaving any feedback that is negative. Once we receive your message, we will make sure to take care of you as timely as possible. By purchasing this item you agree to the terms and conditions stated above. Happy Shopping! Copyright © theclearancecat All Rights Reserved
