Franklin Electric 2366529020 Deep Well 6" Submersible Pump Motor 200v, 10hp -new

US $1,300.00

Jacksonville, Florida, United States
Jun 20th

Open on mobile:
QR code

Franklin Electric 2366529020 Deep Well 6" Submersible Pump Motor 200-Volts 10HP – NEW Manufacturer: Franklin Electric Model: 2366529020 Description: Water Well w/o Subtrol Motor 6" 10-HP 200-Volts 60-Hz Three-Phase 3-Wire - Standard – for most water wells Application data: These motors are built for dependable operation in 6-inch diameter or larger water wells. Temperature and time ratings are continuous in 86 °F (30 °C) water at 1/2 ft./sec. flow past the motor. Rotation: single-phase, CCW facing shaft end; three-phase, electrically reversible. Specifications: Type: Water Well - Standard – for most water wells 10HP - 7.5kW 200-Volts 60-Hz Three-Phase 3-Wire 60 Hz - 3,450 RPM Motor Design: 3-Phase Motor Sub Application: Deep Well Submersible Pump Full Load Amps: 32.7 Thrust Rating: 3500 lb Voltage: 200 Hz: 60 Phase: 3 Number of Wires: 3 HP: 10 RPM Range: 3001-3600 Nameplate RPM: 3450 Max. Ambient Temp.: 86 Degrees F Height: 25 13/32 in Lead Length: 150 in Overload Relay Max. Amp Setting: 37.0 Motor Shaft Rotation: CCWSE Shaft Material: Splined Stainless Steel Diaphragm Type: Pressure Equalizing Overload Relay Amp Setting: 34.0 Stator Type: Hermetically Sealed Motor Service Factor: 1.15 Starter Required: 3DA90 Motor Thermal Protection: None Overload Relay Required: 3DE27 Max. SF Amps: 37.0 Shell Material: Corrosion Resistant Stainless Steel Dia.: 6 in Motor Enclosure Design: Totally Enclosed Nonventilated Castings Gray Iron Stator Shell 310 SS Stator Ends Low Carbon Steel Shaft Extension 303 SS, Except 17-4 SS on 40 hp Fasteners 300 & 400 Series SS Seal Cover 304 SS & Sintered Bronze Seal Carbon/Ceramic Face Diaphragm Nitrile Rubber Diaphragm Plate 304 SS Diaphragm Spring 302 SS Slinger Nitrile Rubber Lead Wire (or Cable) XLPE Lead Potting Epoxy Item is new in sealed original packaging (crate) as shown on the images. The pictures are showing the actual product the buyer is getting. International buyers are responsible to pay for the applicable importing fees and duty if it applies. Thank you for looking. Warranty: Please note that I am not an authorized dealer for any of the products I sell. Therefore I cannot guarantee that the item in this listing will be covered by the manufacturer's warranty or support. For verification purpose I can provide SN for potential buyers before the purchase upon request. Return Policy: If the item you purchased was misrepresented by me or it was damaged during shipping, you can obtain a full refund. In order to receive your refund, you must notify within 30 days of receiving your item. In case you have received the item in a damaged condition you must keep all packaging material for inspection and please notify me ASAP after receiving it and please provide pictures. Full refund (including original S&H) only applies for defective items and it must be sent back in the original condition; including the original accessories and all packing materials. Restocking Fee (up to 15%) will be charged for any item without original package, abused, altered, or damaged. I will not accept returned items with missing accessories or packaging. Returns require my approval and return authorization and item must be received by me before I can issue your refund. Please note: I record all serial numbers to discourage fraud.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	United States
MPN	2366529020
Type	Well
Brand	Franklin Electric
UPC	Does not apply
