Free Shipping, 4pcs/lot Ims-2a/30a/3v-15v Single H Bridge Motor Driver Module

US $49.99

  • ???, ??, China
  • Feb 26th
Open on mobile:
QR code
Free shipping,4pcs/lot IMS-2A/30A/3V-15V Single H Bridge Motor Driver Module PID for Smart RC Intelligent  Car 200 kHz(MAX) PWM Descriptions: - Designed for Arduino intelligent car, the whole bridge DC brush motor drive,for Coreless motor is very good,PID program source send by email. - This drive brake quickly, and  easy to operation. The customers evaluation that its better than the MC33886 etc. - The driver use the whole bridge drive chip + extremely low impedance MOSFET.make the MOSFET switching losses to lowest. Improve power utilization rate. - MOSFET drive chip with hardware brake function and power feedback function. - The current shock resistance MOSFET type, can quickly make MOSFET open channel, improve the speed of the motor curvature, also canrapid in electrical braking. This can make of car can quickly start also can quickly kill car. - Drive can work at 0%-98% of the PWM duty cycle, because the drive is NMOS circuit,NMOS circuit features is not to 100% PWM, when PWM 100% of control circuit,long time carries out the operation can lead to drive damage   Performance parameters: - Rated voltage: 3 V-14.6 V(linmt voltage) - IMS-2A &IMS-2B,R1 short circuit, V+ and B + short circuit. V+ output voltage and drive the input voltage. - IMS-2C,R1 open circuit, V+ and B + disconnect.   V+ input voltage 3-12 V. - Rated current: 30 A(IMS-2A) - Current peak: 70 A(IMS-2A) - Switching frequency: 1 K to 200 kHz - Dimensions: 5.0 cm (long) * 5.0 cm (wide) * 3.5 cm (high)       Pin Defination: - V +               Power Input + - GND              Power Input  - IN1               Forward PWM input, high active - IN2               Reverse PWM input, active high - EN                Driver Enable, high enable, low off - CT                Current signal output,analog signal - VT                Voltage signal output, analog signal   Package include: - 4x Driver module   Dear buyers: Welcome to my store!Thanks! To each transanction,your satisfy is our aim.  If you are satisfy with us,pleae leave five star positive feeback,and welcome to our store again,we will supply the good items and service all the time. If you are not 100% satisfied,Please don't leave a neutral or negative but contact us First, we will do our best to solve for you. Your sincerely  WINGXINE
