Freescale Coldfire Mcf5227x Touch Screen Evaluation Board And Demoqe128 Board

US $80

Milwaukee, Wisconsin, United States
Jan 29th

Open on mobile:
QR code

Two Freescale development kits! The first MCF5227x touchscreen LCD Eval board M52277 External Interfaces: • On Board Sharp 240 x 320 color touch screen LCD panel • 60 pin external LCD connector • Synchronous Serial Interface (SSI) connected to audio CODEC • USB Support — MCF52277 on-chip OTG transceiver with device, host, and OTG support (Mini-AB receptacle) • Crystal/Clock • BDM/JTAG • Two UARTs • FlexBus • Timers • External Interrupts • CAN Support — External CAN transceiver (DB9 connector) • University Breakout Connector for serial interfaces (I2C, QSPI, GPIO, etc.) Memory Subsystems: • 32M x 16 Mobile DDR • 8M x 16 NOR Flash • 16Mbit Serial Boot Flash Power: • Inputs: — 5 V Input to the voltage regulator circuitry • Regulated On-board voltages: — 3.3 V - I/O Voltage — 1.8 V - Mobile DDR and Flash Voltage — 1.5 V - MCF52277 Core Voltage Comes with USB drive with demo code as well as a 1 gig mini scan disk card The board is from a Startup that went belly up. It powers on. comes with power cord and USB cord Software Code Warrior Development Studio. The Second board (I am getting out of the freescale business) The DEMOQE128 is a low-cost development system designed for demonstrating, evaluating, and debugging the FreescaleMC9S08QE128 and MCF51QE128 microcontrollers. The board supports two interchangeable plug-in daughter cards to quickly evaluate the 8-bit S08 and 32-bit ColdFire V1 QE128 MCUs. Embedded Multilink circuitry on the DEMOQE128 board allows the microcontroller on the DEMOQE128 to be powered, programmed, and debugged via USB from the PC. In addition, the demo board contains an on-board logic analyzer and virtual serial port via USB to assist with rapid development.It also supports plug-in RF daughter cards for SMAC and 802.15.4. Interchangeable 8-bit S08 and 32-bit ColdFire V1 QE family daughter cards P&E's USB Embedded Multilink circuitry eliminates the need for external BDM cable Allows for debug, programming, and power to board and device SCI signals connected to Multilink through jumpers for on-board virtual serial port TPM signals connected to Multilink through jumpers for on-board logic analyzer User Features: 3-axis Accelerometer w/ Enable Eight user LEDs w/ Enable Four user push buttons w/ Enable One Piezzo buzzer w/ Enable One RS-232 Serial Port w/ DB9-F Connector IIC Pullups w/ Enable 10K Ohm POT w/ Enable Flexible power input sources selectable through jumpers USB Cable: 5VDC, 500mA max 5VDC to 12VDC power jack: 2.5/5.5mm barrel connector, center positive 2 AAA battery cells MCU port connector ON/OFF power switch w/ LED indicator Selectable regulated VDD Output at 3.0V or 2.1V RESET push bButton and LED indicator w/ Enable External crystal circuitry layout Board Size 3.5 x 4.0'' The kit comes with other external boards I'm tossing in as giveaways. a lot come with this, about 1000 in dev boards. Email for questions

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Freescale
MPN	MC9S08QE128
Model	MCF5227x
