FreeWave FGR-115RC and FGRO9TS Radio Wireless Data Transceivers, US $390 – Picture 0
FreeWave FGR-115RC and FGRO9TS Radio Wireless Data Transceivers, US $390 – Picture 0

Freewave Fgr-115rc And Fgro9ts Radio Wireless Data Transceivers

US $390

  • Yorba Linda, California, United States
  • May 28th
Open on mobile:
QR code
For sale are two FreeWave Radio Wireless Data Transceivers.  They have very little usage and include power supplies, programming cables, three antennas, and other accessories (see pictures).  Both transceivers were tested to communicate with one another. FGR-115RC Specifications Operating Frequency: 902 to 928 MHz Type: Frequency Hopping Spread Spectrum (FHSS) Transceiver Modulation: GFSK, 115.2 kbps or 153.6 kbps Hopping Bands: 7, user selectable Hopping Channels: 50 to 112, user selectable Frequency Hopping Patterns: 15 per band, 105 total, user selectable Occupied Bandwidth: 230 kHz Transmitter Power Output: 100 mW to 1 W (+30 dBm) Antenna Connector: Type N Female Receiver Sensitivity: -108 dBm for 10-6 BER -110 dBm for 10-4 BER Operating Temperature Range: -40° to +75°C Power: 6 to 30 Vdc I/O Data Rate: 38,400 to 115,200 bps RS-232 Connector: 9-pin “D” DCE Average Current Drain: 6 mA sleep, 21 mA idle, 86 mA while receiving, 500 mA while transmitting Weight: 441 g (15.5 oz) Dimensions: 16.5 x 7.4 x 5.7 cm (6.5" x 2.9" x 2.2") FGRO9TS Specifications: Frequency Range 902-928 MHz Method Frequency hopping spread spectrum Hopping Patterns 15 per band, 105 total, user selectable Hopping Channels 50 to 112, user selectable Hopping bands 7, user selectable Range, Line-of-sight 60 miles Occupied Bandwidth 230 KHz Modulation GFSK, 144 ~ 188 Kbps RF Connector Type SMA System Gain 140 dB   Environment and mechanical: Operating tempertature -40 °C - +75 °C Dimensions (single board) 127 L x 61 W x 18 H [mm] 5.0 L x 2.4 W x 0.71 H ["] Weight (single board) 74.4 g 2.6 oz
