Frequency Generator Kit - FG085, US $50.00 – Picture 0

Frequency Generator Kit - FG085, US $50.00 – Picture 1

Frequency Generator Kit - FG085, US $50.00 – Picture 2

Frequency Generator Kit - FG085, US $50.00 – Picture 3

Frequency Generator Kit - Fg085

US $50.00

Miami, Florida, United States
Feb 13th

Open on mobile:
QR code

Function generators are useful in a ton of applications from RF to embedded logic. They’re not usually super cheap though. Good news: we found a kit. The FG085 MiniDDS Function Generator is a ‘some assembly required’ kit that becomes a flexible, functional and easy to use frequency generator. Just solder the through-hole parts in place, attach the face/base plates and before you know it you’ll be generating sinewaves at frequencies up to 200KHz! But that’s only one of the tricks this thing can do. Three different operating modes allow the FG085 to generate 7 different types of continuous waveform as well as servo test and control signals in micro-second resolution. The LCD screen and menu system make this an easy instrument to operate. Frequency, amplitude and offsets can all be set with the number pad and incrementally adjusted with the rotary encoder. The incremental step size can even be adjusted to make sweeps over a wide range easier to handle. The FG805 can generate a peak to peak amplitude up to 10V with an offset range from -5 to +5VDC. It can even be used as an adjustable DC voltage source by setting the amplitude to 0. Includes: FG085 miniDDS Function Generator PCB with SMT parts installed Acrylic Faceplate and Baseplate Alphanumeric LCD and Headers Through-hole Parts Bag 15VDC 1A Wall-wart Power Adapter Quickstart Assembly Guide Output cable (BNC + clips) Features: Generates continuous waveforms of Sine, Square, Triangle, Ramp (up and down), and Staircase (up and down) Generates servo test/control signals in micro-second resolution with user programmable pulse width, amplitude, and cycle Set the frequency (or period), amplitude, and offset with number pad - quick and straight-forward Frequency (period), amplitude, and offset can be incrementally adjusted with rotary encoder Settings are memorized after power down Can be used as an adjustable DC voltage source by setting amplitude to 0 Frequency range: 0 - 200KHz (Sine) Frequency resolution: 1Hz Period resolution: 1ms Amplitude range: 0 - 10V peak-to-peak Offset range: -5V - +5V Memory depth: 256 bytes Sample rate: 2.5Msps Output impedance: 50 ohm Power supply voltage: DC 15V Current consumption: < 150mA (without loading) Dimension: 155 X 55 X 30 mm Net weight: 100 gram We offer the great products with guaranteed quality. Shipping Terms: Your order will be processed within 1 to 2 business days after receipt of cleared payment. Transit time varies on shipping option. We will automatically email you with tracking information as soon as we process your order, within 1 to 2 business days. We only ship to the verified PayPal address supplied to us by eBay/PayPal Payments: We Accept Payments Via PayPal Only Sales Conditions: 14 days in order to get your money back or item exchange, buyer pays return shipping Buyers Pay for Return Shipping Cost 20% restocking fee will apply on all new items that have been opened and returned (except defective) Do not return the item before contacting us. Any return must include a return authorization number provided for us. After you report any problem wait for our answer. Item must be returned within 3 days after RMA instructions has been provided

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	KIT-11394
Country/Region of Manufacture	United States
