Fujitsu 1.55um 8-ch Tunable 10gb Dwdm Transponder, P/n: Fim83011/5252w9240, Fim8

US $750

Ottawa, Ontario, Canada
Jan 29th

Open on mobile:
QR code

1.55um 8-ch tunable 10Gb DWDM transponder, Fujitsu P/N: FIM83011/5252W9240, FIM83011/5352W9540, FIM83011/5352W9490, FIM83011/5352W9340, FIM83011/5052W9590, FIM83011/5052W9490. With dual-drive 10Gb modulator and 20mW PMF CW laser. Min order qty is 4pc if you buy at ebay. For products options, please contact us. Contact us, then we will tell you how to find more photos, actual available qty, data sheet, test data, and correct shipping cost info. DESCRIPTION: 1.55um 8-ch tunable 10Gb DWDM transceiver. Wavelength is based on Wxx in P/N. See very similar model FIM83010 datasheet in 1st pdf link. See new-model datasheet in 2nd PDF link. It is also similar to FIM83110Wxx. See 10Gb APD receiver at the 4th pdf link below, see similar-mode datasheet for PMF CW laser at the 3rd pdf link below. This transponder module includes following three optical components: 1. One dual-drive 10Gb modulator (Fujitsu P/N: H74M-5208-J098 for transponder models FIM83011/5252W9xxx and FIM83011/5352W9xxx; Fujitsu P/N: H74M-5208-J131 for transponder model FIM83011/5052W9xxx), it looks similar to FTM7921ER, except that two RF ports are without connector interface, two RF copper stripes are soldered on PCB, the other 3 soldering points around RF solderings are ground, as shown at the 7th, 12th, and last 4 photos below. Fibers are in 900um buffer, input PMF fiber is without connector in black color, 0.7 meter long. Output SMF fiber is with MU connector(with boot parts in small bag, so connector is in full kit) in blue color, one meter long. You can buy it separately at Store Product Code: OSC-MOD-10Gb-016Q, where we will remove laser and receiver from transponder module and sell rest with PCB to you as modulator. 2. One PMF CW laser (Fujitsu P/N: FLD5F15CA/002W9xxx, it is 20mW laser since specification at last 5 pdf links below show output >3dBm, and Fujitsu FIM83-seires 80-km MZLN-LD type transponder output specification >3dBm. Fiber is in 900um red buffer without connector, about 0.54 meter long. We can desolder and remove the laser module from PCB, so you can buy it separately at Store Product Code: OSC-LDPM-C-014S. 3. Up-to-12.5Gb APD receiver (Eudyna P/N: FRM5N141GW). See this APD receiver at 4th pdf link below. Fiber is in 900um yellow buffer with MU connector(with boot parts in small bag, so connector is in full kit), one meter long. We can desolder and remove the receiver module from PCB, so you can buy it separately at Store Product Code: ODC-Rx-10Gb-030P. Product options: FIM83011/5252W9240, tunable over 1558.173 – 1561.013nm, with laser FLD5F15CA/002W9240 FIM83011/5352W9540, tunable over 1534.250 – 1537.003nm, with laser FLD5F15CA/002W9540 FIM83011/5352W9490, tunable over 1538.186 – 1540.953nm, with laser FLD5F15CA/002W9490 FIM83011/5352W9340, tunable over 1550.116 – 1552.926nm, with laser FLD5F15CA/002W9340 FIM83011/5052W9590, tunable over 1530.334 – 1533.073nm, with laser FLD5F15CA/002W9590 FIM83011/5052W9490, tunable over 1538.186 – 1540.953nm, with laser FLD5F15CA/002W9490 Photos 3-7 are for FIM83011/5252Wxx. Photos 8-12 are for FIM83011/5352Wxx. Photos 13-16 are for FIM83011/5052Wxx. Photos 1-2 and last 3 photos are for all models. FIM83011/5252Wxx and FIM83011/5352Wxx are made in 2007 or 2006. FIM83011/5052Wxx is made in 2003. CONDITION: new in original product box. With manufacture test data, see last 5 pdf links above. We opened sample modules only to see what inside. SHIPPING INSTRUCTION: Buyer will pay actual shipping cost by TNT, UPS, or Canada post. Ebay listed shipping cost is incorrect !!!. Buyer can also use your UPS/TNT/Fedex/DHL shipping account. USA buyers: No customs fee to USA address.
