Fuyu Fsl40 Linear Guide Slide Table Ball Screw Motion Rail Cnc Linear Guide S...

US $210.79

Phoenix, AZ, United States
Aug 21st

Open on mobile:
QR code

FUYU FSL40 Linear Guide Slide Table Ball Screw Motion Rail CNC Linear Guide Stage Actuator Motorized Nema 23 Stepper Motor[100mm Stroke] Special made nema 23 stepper motor with max speed up to 1200 rpm Quality ball screw with accuracy up to ±0.03mm,also low noise when working M4 screw on sideways to install end stop,and on base board for easy installnation Oxided aluminum avoid rusting,extra support unit enhanced stability have multi length stroke options from 50mm to 1000mm linear guide for cnc device Effective Stroke: 100mm Total Length: 299mm Tatal Height: 80mm Slide Width: 40mm Maximum Horizontal Load: 25kg Maximum Vertical Load: 15kg Max Horizontal Speed: 150mm/s[max loading] Max Vertical Speed: 88mm/s[max loading] Ball Screw Model: G1610 Ball Screw Accuracy Class: C7 Stepper Motor Parameter: Rated Voltage: 1.7v Step angle:1.8° Motor flange size: 57mm Motor length: 56mm Holding torque: 0.95 N.m Current: 2.0A Resistance: 1.32 FLS40 Series G1610 Ballscrew Linear Guide with Nema23 Stepper Motor ASIN: B07CYT75HZ 50mm stroke ASIN: B0784G4TYM 100mm stroke ASIN: B077Q7QGF6 150mm stroke ASIN: B077Q8T6Y3 200mm stroke ASIN: B078BQ6NBD 250mm stroke ASIN: B077QLVRRB 300mm stroke ASIN: B077QD96W1 350mm stroke ASIN: B0784G53D4 400mm stroke ASIN: B077QHNCS7 450mm stroke ASIN: B077Q8LVLW 500mm stroke ASIN: B0784FYLWV 600mm stroke ASIN: B077QD97SW 700mm stroke ASIN: B078BPZM1T 800mm stroke ASIN: B077QHND39 900mm stroke ASIN: B0784G58S7 1000mm stroke Please contact us when you need suggestions on choose this kind of item Shipping We offer FREE shipping on all orders! We ship within Three business days of payment, usually sooner. We use a selection of shipping services such as UPS, FedEx, USPS etc. We only ship to the lower 48 states, no APO/FPO addresses or PO Boxes allowed. Local pickups and combined shipping options are not provided at this time. Return You can return a product for up to 30 days from the date you purchased it. Any product you return must be in the same condition you received it and in the original packaging. Please keep the receipt. Payment We accept payment by any of the following methods: PayPal Please pay as soon as possible after winning an auction, as that will allow us to post your item to you sooner! Feedback Customer satisfaction is very important to us. If you have any problem with your order, please contact us and we will do our best to make you satisfied. Contact Us If you have any queries, please contact us via ebay. We usually respond within 24 hours on weekdays. Please visit our eBay store to check out other items for sale! Thank you for shopping at our store.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Size	100mm
Model	Does not apply
MPN	Does not apply
Brand	FUYU
UPC	661021656845
ISBN	0661021656845
EAN	Does not apply
