G4-rtahd1 16 Channel Dvr Used

US $90.00

Lakewood, Ohio, United States
Jan 30th

Open on mobile:
QR code

NOTE: DVR does not come with cables, mouse, or HDD, but is otherwise in working condition. GENERAL -Video Inputs 4,8,16 inputs, 1.0Vp-p, 75? unbalanced -Video Outputs 3 Main monitor outputs -HDMI/VGA/Composite -Individual channel loop outs -1 Spot Monitor -Audio Inputs 4,8,16 audio inputs (200-2800mV, 30K?) -Audio Outputs 1 audio output (200-3000mV, 5K?) -Voice Interface 1 (200-2800mV, 30K?) -Audio Compression G.711, 64kbps ADPCM (VOIP standard) -Video Compression H.264 -Preview Resolution NTSC: -HDMI/VGA 1280x1024, 1280x720, 1024x768 -Composite 800x600 -Compression Resolutions NTSC: 704 x 480 (4CIF) -NTSC: 704 x 240(HD1) -NTSC: 352 x 240 (CIF) -Color 16.7 Million -Stream Type Video or Video/Audio -Bit Rate 56kbps ~ 2Mbps (user-defined), variable -Recording Frame Rate 4CIF Resolution: 30 frames/sec/channel -Record Quality Highest, Higher, High, Average, Low, Lower, Lowest -Record Mode Schedule, Motion, Alarm (simultaneous or combination) -Playback Mode Date/Time Search or Event Search -Operation Mode Pentaplex (simultaneous monitor, record, playback, network, and backup) -Motion Detect Area Division: 22 x 15, on/off selectable Motion Detect and Relay On Simultaneous -Privacy Masking Alerts Yes -View Tampering Alerts Yes -Network Function Internet Explorer and Client Software -Alarm 16 Alarm Inputs / 6 Relay Output -Back-up DVD-RW / USB / Network/E-SATA -RS485 Keyboard Controller / PTZ -HDD Interface 8 SATA. Internal bracket supports 6 HDD -plus 1 DVD-RW or 8DD without DVD-RW -HDD Management Hibernation, HDD faulty alarms, RAID (redundancy) -VGA Interface 1, Support 800x600/60Hz, 800x600/75Hz, 1024x768/60Hz TECHNICAL SPECIFICATIONS MECHANICAL -Video Inputs BNC female -Video Output BNC female -Monitor Output HDMI, VGA, BNC -Audio Inputs Channels 1-4 BNC female, remaining are -RCA female -Audio Output BNC female -Alarm Inputs Screw Terminals -Alarm Outputs Screw Terminals -RS485 Screw Terminals -Network RJ-45 10M/100M UTP -VGA 9-pin D-sub female -USB USB 2.0 Type A port -IR Remote Controller Standard, Addressable -Voice Interface RCA female ELECTRICAL -Power Requirements 110V 60 Hz, 220V 50Hz -Power Consumption 22W ~42W (without HDD) ENVIRONMENTAL -Operating Temperature 32 -Operating Humidity 10-90% RH Max. PHYSICAL -Dimensions 19in. 2U 440(w) x 89(H) x 460(D)mm -Weight 20 lbs aprox. (without HDD)
