Ge 110071001 ^16 Digital Outputs 16do Micro5

US $216

Howard Beach, New York, United States
Jan 30th

Open on mobile:
QR code

16 DO Micro/5 Option, 16 transistor switches, .04A @ 24VDC (max.) COMPATIBLE WITH SP EDITIONS AND PICTURE PERFECTTM SYSTEMS The Micro/5 20 DI (Digital Input), 16 DO (Digital Output) and 16 DOR (Digital Output with Relays) option cards provide a costeffective and convenient interface between the CASI access control system and its input and output devices. Micro/5 Options plug into the Micro/5 backplane. Each option has pluggable edge connectors which make field installation and maintenance quick and easy. MICRO/5-PX & MICRO/5-PXN A maximum of four 20 DI and either four 16 DO or four 16 DOR options can be configured into the available Micro/5-PX, or -PXN card slots. These input and output points are in addition to those provided on the 2RP, 2SRP and 8RP reader processors. SUPERVISED DI POINTS The 20 DI option has full four-state supervision on all digital input points, providing the means to remotely sense line condition. Supervised states are closed, open, line short and line open. ECONOMICAL System input and output devices can be located up to 1,000 feet from the related microcontroller. This reduces installation costs, as microcontrollers do not have to be near the monitoring device. FLEXIBLE DO DEVICES The 16 DO and 16 DOR options make it possible to incorporate a complete range of output devices into an access control system. The 16 DO may be used to drive low current or isolated devices or to drive low current devices directly. Alternatively, an external relay may be used for higher current devices. The 16 DOR includes integral relays, each of which can switch up to two amps at 40VDC. Each card uses autoreset fuses to protect the electronics from short circuits that may occur during installation. FEATURES • Compatible with all CASI access control systems • Compatible with all CASI Micro/5 microcontrollers • Options plug into the backplane for quick installation • Screw-terminal connectors eliminate field wiring problems CONFIGURATION INFORMATION • DI point supervision resistors should be installed as close as possible to the point being supervised • 16 DO has 16 transistor switches, each able to switch .04A @ 24VDC • 16 DOR has 16 2A @ 40VDC / 30VAC relays on board • 20 DI and 16 DO wiring, 22AWG shielded, stranded recommended • 16 DOR wiring, 12 to 22AWG shielded, stranded recommended

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	GE
MPN	GE CASI RUSCO
Model	110071001 REV F
