Ge Total Lighting Controls, Plc To Tlc Rtr32 Relay Controller Card (rr9 Rr7 Rr8)

US $125.00

Glen Burnie, Maryland, United States
May 14th

Open on mobile:
QR code

This listing is for a GE Total Lighting Control RTR32 Relay Controller Card, an upgrade module for a GE Programmable Lighting Control (PLC) panel. Please see pictures of tech info and the info cut-and-pasted below. It is in excellent condition and has been fully tested. Satisfaction Guaranteed. Free Priority Mail shipping. You are bidding on the actual board you see in the pictures. Some item specfics: Upgrading to TLC: The RTR32 Relay Controller Card is an intelli-gent upgrade module for a GE Programmable Lighting Control (PLC) panel. It provides a path from PLC to the more fully-featured Total Lighting Control (TLC) system architecture. Most older GE systems fall into two categories: ETA panels with an ECON Controller, or SRC panels with no central controller. (Refer to “Upgrading PLC To TLC” on the next page for a summary of system components.) To upgrade these panels to TLC, simply replace the existing Relay Controller and Switch Interface Cards with the new RTR32 and RTS16 modules. Upgraded panels can coexist with older panels until the whole system is converted to TLC. Note: The original type of PLC system, a BCON Controller with BTA panels, can also be upgraded using an additional kit, the RTLCCAN. DESCRIPTION FEATURES: Total Lighting Controls PLC To TLC Relay Controller Card. The RTR32 Relay Controller Card replaces the ER16 or ER32 card in an existing ETA panel, or the SRCM-R card in an SRC panel. The motherboard in these panels requires one relay controller card to provide full monitoring and control for up to 32 relays. If an ES8, ES16 or SRS16 switch interface card is also present in the PLC panel, it must be upgraded to an RTS16 at the same time as the RTR32. The RTR32 gives ETA panels distributed intelligence, eliminating the need for a central controller and allowing the panels to run independently. In addition, all upgraded panels will gain built-in lighting control scenarios and advanced communications capabilities. The RTS16 provides programmable switch interfaces and works with the RTR32 to provide full panel control and monitoring. • Simple plug-in modules. • No rewiring of relays necessary. • 32-relay control capability. • Used with the RTS16, up to 16 global switch inputs available. • Built-in programmable lighting scenarios. • Indirect relay switching. Each relay in the panel can only be controlled by the RTR32. There are no landing points for local switches or occupancy sensors. • Runtime and status information for all relays. • Memory backup during power outages

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	GE
Brief Description	Relay Controller Card
Application	Light Control
Country/Region of Manufacture	United States
Authorized	Fully Authorized
MPN	RTR32
Quantity Listed	1
UPC	Does not apply
