Gecko G540 Controller (revision 8 2013 Date Code) Complete Diy Package

US $375.00

Spring Hill, Florida, United States
Jan 30th

Open on mobile:
QR code

This is auction is for one Gecko G540 Stepper Controller, and 48V 8.3a power supply motion controller DIY package. Please take a few minutes to read this auction completely to understand how complete this package is. This package will completely control a 4 axis high torque system utilizing all 3.5a the Gecko provides. Gecko's Basics For Picking a Power Supply. The easiest factor in choosing a power supply is its current rating, which is based on your motor ratings. The easiest way to find out a the amps required is to divide your motors amp by 3 if you plan on connecting the motor in series (full winding) or divide by 3 then multiply by 2 to find out the amp requirement for each individual motor for parallel (half winding) Remember to multiply the requirement of a single motor by how many axis your machine will be. *Example: 3.5a motor to be run in Series would be 1.17a for each motor or a total of (1.17x3)= 3.51a for a three axis machine a four axis would require (3.51a+1.17a)= 4.68a* This package features our 48v 8.3a power supply that will easily supply a 4 axis system with enough current as shown above in Gecko's direct explanation on picking a power supply. Click on the picture to review the power supply specs. Refreshing the page after you click the picture link will let you continue down the page reading the auction. This controller is the new revision 8 model with 2013 QC date code. This is for a complete package. This package features the mandatory items to make the Gecko a usable controller minus the cooling system, and enclosure. this package saves time, and money as it includes all the items you will require just to power the Gecko up. No one sells it this way, and that's silly cause it makes you spend more than is required from other vendors. This is a COMPLETE hookup an play G540 package. Take a moment, and use Google on pricing the Gecko, and what's featured in this auction, and you will soon see to build this package would easily exceed $365 with shipping. This is Simply the best deal anywhere online for a COMPLETE G540 package. Due to such high turnover on these. If they are on order they wil ship within 4 days. There's a reason these don't last long with this package. If you want to review any packaged compnents simply click on there picture for their specs. 1 DB25 Parallel port male to male cable 6ft. (picture listed above) The standard four DB9 clamshell connectors are included, but you can Add 3 Solderless motor connectors with mounting brackets for $22!! Review them here for the easiest way to setup your system. 3 Omron Snap Switch V-156-1C25 (Limit Switch) Long Roller Lever 39Ft of Shielded 18AWG 4 lead copper core cable with ground wire, and E-stop switch (The switch is a full size unit unlike the picture) (this cable should be used throughout your setup for optimal performance. (The amount of cable provides 3 6Ft limit switch cables, 3 6Ft. motor cables with 3Ft left to wire the Gecko in your enclosure.) 1Ft of 4mm heatshrink to make your wires professional grade. Please check my other auctions. If you are going to purchase more than one item please message me to combine shipping. I also have complete packages with motors, CAM Software, and Mach3, . My prices are worth taking the time to message me about. USPS shipping is FREE in the US. Intenational shipping welcome with adjusted shipping price. Please message me prior to bidding. Gecko G540 Specs Four 10-Microstep motor drives 0 to 3.5A rated phase current 18VDC to 50VDC supply voltage Mid-band resonance compensation Auto standby current (70% current) Short-circuit protected Optoisolation on all LPT signal pins Two 1A at 0 to 50VDC rated outputs Four SPST to GND inputs (TTL) FAULT indicator LED,signal to PC POWER indicator LED I-SET resistor on motor connector TRIM adjust for motor smoothness Panel mount (5.7” by2.4” hole dim.) Anodized aluminum package No heatsink needed below 40C ambient Easy to service, removable drives Modular PCB design with no internal wires 10kHz watchdog timer (charge pump) Optoisolated analog output for a VFD drive Conservative ratings, premium components Comes with four backshells and four DB9 solder cup connector
