Geiger Counter Kit Module Miller Tube Gm Tube Nuclear Radiation Detector Diy

US $43.45

  • Shenzhen ,Guangdong, China
  • Aug 18th
Store CategoriesStore Categories eBay Motor Fashion Books, Movies & Music Electronics Collectibles & Art Home & Garden Sporting Goods Toys & Hobbies Business & Industrial Health & Beauty Other Product View Detail Radiation Detector Kit Description: Name:Radiation Detector system Geiger tube parameters: Technical parameters diameter:Φ10±0.5mm Total length: 90±2mm Starting voltage: Recommended operating voltage: 380V Minimum plateau length: 80V Maximum plateau slope: 10%/80V Extreme operating voltage: 550V The maximum count rate: 25 times / min Life: > 1 x 10^9 pulse Medium temperature: -40 ~ 55 Size:108x63x20mm Features: 1) 5V power supply, or 1.5V 3x battery; 1.2V 4x battery, current: 30mA - 12mA 2) for the detection of 20mR/h ~ 120mR/h of gamma rays and 100 ~ 1800 off variables / points / cm 2 of the soft beta ray. 3) sound and light alarm 4) interrupt the output interface, through this interface can be connected to the microcontroller and then displayed on the LCD. 5) Ardunio compatible 6) supports most of the Geiger tube: M4011, STS-5, SBM20, J305, etc. (the 330~600V operating voltage of the Geiger tube can be supported). 7) support the computer (PC) data acquisition, Matlab analysis and processing Detection of nuclear radiation work (copy the following link to the browser to watch): Http://v.youku.com/v_show/id_XNzI3MTU2NzQ0.html Customers using our Geiger counter to record the video: Http://v.youku.com/v_show/id_XOTE4ODIyNTIw.html Compatible with Arduino: (recommended UNO R3 Arduino, or any other arbitrary with 5V and external interrupt INT) Internet can be downloaded: SPI example for Radiation Logger Arduino Logger Radiation can be used as the host computer software to build radiation monitoring station. Package included: 1 x Assembled Radiation Detector system 1 x GM Tube 1 x Power supply cable 1 x Battery Holder (without batteries) 3 x Jumper Wires 4 x Nuts 1 x Acrylic cover 2PCS Tester sensor Description: This sensor contains tiny amount of Americium 241 isotope. Americium emits alpha particles and weak gamma radiation, alpha particles completely blocked by the casing of the sensor, gamma radiation however freely passes through the casing but due to very low energy around 60 keV quickly absorbed by air (maximum run through air 15cm). It is a great source for checking gamma only sensitive Geiger counters, if you have such type of counter it will be impossible to test it with other sources which emit beta particles only. It could be used to test gamma spectrometers as well. Add a nice "hot" piece to your collection which emits alpha and gamma radiation. SBM-20 tube based Geiger counter indicates 140 Counts per minute from this source with gamma filter applied (approximately 80 uR/h or 0.8 uSv/h accordingly). Specifications: Ionization source characteristics and radiation safety performance: The ionization chamber fitted with a high performance and low activity of Am-241 ionization Ionization source activity: 0.5uCi ( 18KBq ) 0.8uCi±10% ( 30KBq±10% ) Ionization source a spectroscopy: peak: 4.5MeV ± 10%, FW HM Safety grading standards ( GB4075, IS02919 ) C64444 Ionization chamber radiation dose rate at 25cm: 0.03mGy/ (1mGy value lower than population dose standard) Ionization chamber specification, parameter: Conditions: outer electrode and the source electrode voltage ( VDD supply voltage ): 9V Environment temperature: 20 + C: close to atmospheric pressure standard atmospheric pressure, clean air Collecting electrode equilibrium potential: 5.3~6.5V Light reduction rate was 1% feet: 0.6V Light reduction rate was 4% feet: 2.2V Insulator leakage current ( Max ): 0.5Pa Capacitor ( collection of extreme outer electrode + to the source base ): 6.0pF Material: Metal Color: Silver Size: 28 x 16 x 37mm / 0.8" x 1.1" x 0.5" Package included: 1 x Smoke tester sensor Feedback Payment Shipment About us Feedback We appreciate positive feedback . we always try our best to service our customers .   so if you have ant question ,PLEASE DON’T HESITATE TO TELL US,   we are always here to offer help . Payment We prefer PayPal .For purchasing multiple items , please contact us for a combined invoice . generally we would like to receive payment thin 48 hours if .   Shipment We provide airmail service with good package . The items will be shipped within the nest 2 business days after we received the payment . when you buy multiple items ,your shipping cost will be combined with discount . SHIPPING TIME (weekends/holidays excluded)         Country Name Shipping Time Country Name Shipping Time     USA/Canada 10 -15d Spanish/Portugue 10-25d     East/South Asia 10 -15d France/West Asia 10-25d     United Kingdom 10 -20d Italy 10-30d     Australia/New Zealand 10 -15d West Asia/Middle East 15-25d     Most Country of West/North Europe 10-20d South America and Africa 15-30d     East /Middle Europe/Russia 10-25d         About us NEW, GOOD QUALITY, ORIGINAL PACKAGE LARGE STORE AND THE LOWEST PRICE NO-QUESTION-REFUND,             FOR LARGE QUANTITY ,OFFER BETTER PRICE,ORIGINAL        PACKING(TAPE REEL/TUBE/TRAY   We specialize in electronic components . ICs, Capacitors, Diodes, Resistors, LEDs, Transistors, and so on. Especially in Hard To Find Parts . we only sell NEW , ORIGINAL parts . please buy with confidence .We offer NO-QUESTION-REFUND   go to my store
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Extreme operating voltage 550V
Brand Unbranded/Generic
The maximum count rate 25 times / min
UPC Does not apply
Medium temperature -40 ~ 55
EAN Nicht zutreffend
MPN Does not apply
Item Name Radiation Detector system
