Generator Set Controller For Diesel/gasoline/gas Genset Parameters Monitor-dc62d

C $79.66

suzhou, China
May 16th

Open on mobile:
QR code

Product Description Generator Set Controller For Diesel/Gasoline/Gas Genset Parameters Monitor-DC62D Features: 100% brand new and high quality Made of high-quality materials, durable This series of controllers are specially used for starting, stopping, parameter monitoring, fault checking and data setting of diesel/gasoline/gas generator sets. The controller uses a 4.3-inch color LCD screen display with a new UI design, which can directly display relative faults. All parameters can be displayed by analog indicators and text. In addition, the LCD screen can also display various faults at the same time. Once the generator fails to operate normally, the generator set will stop running. There are Chinese and English interface options, and more languages can be set according to user requirements. All parameters can be configured through the buttons on the front panel, or adjusted through a PC through RS485 or USB using a programmable interface, and can be widely used in various automatic control systems for generator sets. Using 32-unit micro-processing technology. 4.3 inch TFT color large screen LCD, optional language interface (Chinese/English), user's language can be set if necessary. Display indicators and numbers through the UI interface. Acrylic materials are suitable for protecting screens. silicone board; USB port: Even in the absence of power, you can set parameters through the USD port for real-time monitoring. Various parameters are displayed. Input/output function, status can be displayed directly. More categories of surface settings. Built-in real-time clock: Preset time operation can be performed and automatic maintenance is provided. The generator set work schedule can be set weekly or monthly. Three-level protection countdown function, maintenance time or date can be set. Recording function: relative faults should be recorded in real time. There are a total of 6 relay outputs, of which 4 relay outputs can be self-configurable, and each relay can be set up to 25 functions. In addition, there are 4 groups as non-contact terminals. 5 switch inputs, each can set up to 30 functions. 3 sensor analog input connectors, 6 input types are configurable, and various units can be set. The battery charging control function can protect the battery according to the battery voltage state. The sensor can be customized via front buttons or PC software. Adapt to 3P4W, 1P2W, 2P3W (120V / 240V, 50 / 60HZ) Various crank conditions (RPM, frequency, oil pressure) can be selected Control and protection: automatic start/stop of the generator set, load transfer (ATS control) and complete fault display and protection functions. Standard waterproof rubber gasket. Waterproof up to IP54 Modular design: All connections use European connectors, so installation, connection, maintenance and replacement are easier. Parameter display: Engine speed hydraulics pressure Engine water temperature Engine fuel temperature Engine cylinder temperature Engine oil tank temperature Engine oil level Engine battery voltage Charging voltage Power frequency (only for DC62D) Power phase voltage L-N (only for DC62D) Power phase voltage L-L (only for DC62D) Generator 3-phase voltage L-N Generator 3-phase voltage L-L Generator 3-phase current A Generator frequency Hz Generator power factor COS Generator active power KW Apparent power of generator KVA Generator reactive power KVar Current loading rate% Total average loading rate% Power consumption KWH Total power consumption Total start time Current running time Total running time Three-level maintenance notice protection: Speeding Insufficient speed Low oil pressure High water temperature High oil temperature Cylinder temperature is high High water tank temperature Low oil level Low oil level External emergency alert D+ opening RPM loss Sensor open Overfrequency Underfrequency Overvoltage Undervoltage Overcurrent Current imbalance Over power Lack of phase Reverse order Generating load failure Power generation unloading failed Mains load failure Power unload failure Main maintenance due Secondary maintenance due Maintenance due Low water alarm emergency stop Crank failure Battery overvoltage Low battery voltage Charging failed Battery charging failed Stop failed Product parameters: Woking voltage: DC8V ---- 36V continuous energy consumption: Standby: 24V: Maximum 1W Work: 24V: Maximum 5W AC voltage input: 1P2W 30VAC-276VAC (ph-N) 2P3W 30VAC-276VAC (ph-N) 3P4W 30VAC-276VAC (ph-N) Speed sensor frequency: 200-10000Hz Maximum accumulation time: 99999.9 hours (minimum storage time: 6min) Fuel relay output: 16Amp DC + VE supply voltage Start relay output: 16Amp DC + VE power supply voltage Programmable relay output 1: 5Amp DC + VE power supply voltage Programmable relay output 2: 5AMP non-contact-normally open-normally closed output Programmable relay output 3: 5AMP non-contact normally open output Programmable relay output 4: 5AMP non-contact normally open output Excitation output: maximum 1AMP DC + VE power supply voltage Switch input: available when connected to battery- Working conditions: -20-65degree Celsius Storage conditions: -40-85degree Celsius Protection level: IP54, when waterproof rubber pad is added between the controller and the panel Dimensions: 210mm * 160mm * 50mm Panel opening: 186mm * 142mm Weight: 0.9Kg Package list: 1 *DC62D generator set controller 1 *Accessories package 1 *Instruction Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours. On 16-May-21 at 14:00:13 EDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Package Contents	1 *DC62D generator set controller Kit
MPN	Does Not Apply
UPC	Does not apply
