Generator Waveform Pulse Signal Source 250msa/s Frequency Meter 20/60/100mhz

US $128.67

Guangzhou 510098, China
Jul 18th

Open on mobile:
QR code

Generator Waveform Pulse Signal Source 250MSa/s Frequency Meter 20/60/100MHz Item Description Generator Waveform Pulse Signal Source 250MSa/s Frequency Meter 20/60/100MHz Features: Adopt the Direct Digital Synthesizer (DDS) technology and provide stable, precise, pure and low distortion signals. 2.4 inch TFT color LCD with 320*240 resolution, simultaneously display parameters and graphics of CH1 and CH2. Adopt MagicPulse Technology, Low Jitter(RMS)<200ps. The instrument uses 14-bit high-speed D/A converter chip (5Vpp output quantization error is less than 1mV), 300MSa/s sample rate, 14bits vertical resolution. Can output up to 99 groups of functions / arbitrary waveform, contains 35 groups of preset waveforms and 64 groups of user-defined waveforms. Preset waveforms: Sine, Square (Duty Cycle adjustable), Pulse (Pulse width and cycle time can be set accurately), Triangle/Ramp, CMOS(012V), Four channels TTL, Exponential Rise, Exponential Fall, Noise, ECG, DC etc. Enable to store 64 arbitrary waveform data files, each one of waveform storage depth 8192 points * 14bits; (The longer the waveform storage depth, the more detail the waveform is saved, and the signal details can be restored with high precision.) Various modulation types: AM, FM, PM, ASK, FSK and PSK modulations. Sweep Function: it can sweep 4 properties of signals including frequency, amplitude, offset and duty cycle; It has Linear and Logarithm two sweep types; 0.01S999.99S sweep time; Up, Down and roundtrip sweep directions. VCO Function (Voltage Control Output): can be achieved by an external input signal: voltage controlling frequency, voltage controlling amplitude, voltage controlling offset, voltage controlling duty cycle and PWM modulations. Burst Output Function: there has Manual Trigger, internal CH2 Trigger, and External Trigger for your options. It can output 11048575 pulse trains. 100M Frequency Meter Function: it can measure frequency, period, pulse width and duty cycle. Max. frequency workable is 100MHz and Min. frequency workable is 0.01 Hz. Counter Function: it has 2 coupling measure modes including DC coupling and AC coupling. This design can solve inaccuracy problem of AC coupling. Standard dual full functional channels which are equivalent to two independent generators. Channel SYNC Function: support waveform copy and state copy between channels. Support two or more signal generators connected to achieve multi-channel output, the maximum support 16-channel synchronous output, the phase between each channel can be adjusted. Precisely adjust the phases of the two channels. Precision can be 0.01°. Min amplitude resolution can be up to 1mV. Amplitude range is 1mV25Vpp. Duty-cycle of each channel can be adjusted independently 0.01%-99.99%, the adjusting resolution is 0.01%. -12V+12V DC Offset function. Resolution 0.001V. Save Function: it can save 20 sets user-set parameters and can be loaded at any time. Communicating Function: all functions can be controlled by PC program and the communication protocol is open for secondary development. Output Short-circuit Protection: all channels can work more than 60 seconds when the load is short-circuited. Provide powerful waveform editing PC software. Users can download arbitrary waveform to this instrument after edit through PC program which is included in user CD. Adopt ABS plastic shell with table type design. Use 100-240V (AC) wide range voltage power supply. Specification: Plug Type: AU / EU / US / UK (Optional) Frequency Model FY6900-100M Sine 0~100MHz Square 0~25MHz Ramp, Triangle 0~10MHz Pulse 0~10MHz TTL/CMOS 0~10MHz Arbitrary Waveform 0~10MHz MinimumPulseWidth 20ns(All models of pulse wave minimum width can reach 20ns) Min. Resolution on all frequency range 1Hz (Min. resolution can reach 1Hz on all frequency range to ensure adjusting accuracy under high frequency. For example, it can output 10.000000000001MHz signal). Accuracy ±20ppm Stability ±1ppm/ 3hours Waveform Characteristics Waveforms Sine, Square,Rectangle (Duty Cycle adjustable), Pulse (Pulse width and cycle time can be set accurately), Triangle/Ramp,Sawtooth Wave, CMOS, Four channels TTL, DC, Half wave, Full wave, Positive Step, Inverse Step, Positive Exponent, Inverse Exponent, Lorenz Pulse, Multitone, Noise, ECG, Trapezoidal Pulse, Sinc Pulse, Narrow Pulse, Gauss White Noise, AM, FM, and other 64 sets customer-defined waveform. Non-Volatile Storage Can store 64 user-defined arbitrary waveforms, (8K 14bits) * 64 Waveform Length 8192points * 14bits Sampling Rate 300MSa/s Vertical Resolution 14 bits Sine Harmonic Suppression 50dBc(<1MHz); 45dBc(1MHz~20MHz); Total Harmonic Distortion <0.5% (20Hz~20kHz,0dBm) Rectangle Rise/Fall Time 7ns (VPP<5V) Overshoot 5% Duty Cycle 0.01%~99.99% (Resolution 0.01%) SawtoothWave Linearity >99% (0.01Hz~10kHz) Output characteristics AmplitudeVPP Frequency5MHz: 1mVpp~25Vpp; 5MHz<Frequency10MHz: 1mVpp~20Vpp; 10MHz<Frequency20MHz: 1mVpp~10Vpp; 20MHz<Frequency60MHz: 1mVpp~5Vpp; 60MHz<Frequency80MHz: 1mVpp~4Vpp; Frequency>80MHz: 1mVpp~3Vpp; Resolution 1mV Amplitude Stability ±0.5%/ 5 Hours Amplitude flatness ±2.5%(<10MHz);±5%(>10MHz) Waveform Output Impedance 50±10%Typical Protection All channels can work more than 60 seconds when the load is short-circuited. DC Offset Offset Range Frequency20MHz: ±12V;Frequency>20MHz: ±2.5V; Offset Resolution 1mV Phase Feature Phase range 0~359.99° Phase resolution 0.01° TTLOutput TTL Level Amplitude >3Vpp Fan-out >8 TTL LOAD Rise/Fall Time 10ns CMOSOutput Low Electric Level <0.3V High Electric Level 1V~12V Rise/Fall Time 18ns External Measurement Function Frequency,Period, Positive/Negative Pulse Width, Duty Cycle Input Voltage Range 1Vpp~20Vpp Frequency Meter Resolution 0.01Hz(Gate Time = 100S) Range 0.01Hz~100MHz Sensitivity Gate Time 3 grades (1S, 10S, 100S) adjustable Counter Range 0-4294967295 Coupling DC, AC Working Mode Manual Period Measurement Range 5ns ~ 20s DC coupling measurement Pulse Width Measurement Range 0ns ~ 20s Resolution 5ns Duty Cycle Range (Display) 0% ~ 100% Sweep Carrier Waveform Sine, Square, Ramp, Arbitrary(except DC) Sweep Type Linear or Logarithm Sweep Direction Up, Down and roundtrip sweep directions Sweep Objects Frequency, Amplitude, Offset, Duty Cycle Sweep Time 0.01S~999.99S/Step Setting range Starting position and Finishing position can be set arbitrarily. Sweep Range Decided by Parameters setting. VCO(Voltage Control Output) Modulation signal range to input 0~5V VCO signal frequency range 0-2000Hz VCO control object voltage controlling frequency (VCF), voltage controlling amplitude (VCA), voltage controlling offset, voltage controlling duty cycle. VCO special function Can Amplitude Modulate (AM) or Frequency Modulate (FM) by external analog signal. Modulation Modulation Type AM, FM, PM, ASK, FSK, PSK Carrier Waveform Sine, Square, Triangle, Ramp,Arbitrarywaveform(Except DC) AM Source Internal (CH2) / External (VCO IN Port) Modulating Waveform Sine, Square, Triangle, Ramp,Arbitrarywaveform Depth 0% to 120% Modulating Frequency Internal:1Hz~1MHz; External: 1Hz~2KHz; FM Source Internal (CH2) / External (VCO IN Port) Modulating Waveform Sine, Square, Triangle, Ramp,Arbitrarywaveform Modulating Frequency Internal:1Hz~1MHz; External: 1Hz~2KHz; PM Source Internal (CH2) / External (VCO IN Port) Modulating Waveform Sine, Square, Triangle, Ramp,Arbitrarywaveform Phase Deviation 0° to 360° Modulating Frequency Internal:1Hz~1MHz; External: 1Hz~2KHz; ASK Source Internal (CH2), External (ASK IN Port), Manual Modulating Waveform Square with 50% duty cycle. Key Frequency 1Hz~10MHz FSK Source Internal (CH2), External (FSK IN Port), Manual Modulating Waveform Square with 50% duty cycle. Key Frequency 1Hz~10MHz PSK Source Internal (CH2), External (PSK IN Port), Manual Modulating Waveform Square with 50% duty cycle. Key Frequency 1Hz~10MHz

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Origin	CN(Origin)
Custom Bundle	No
Model	FY6900
Brand	Unbranded
Modified Item	No
DIY Supplies	ELECTRICAL
MPN	Does not apply
Certification	None
Country/Region of Manufacture	China
