Genuine Hubbell Hbl4200ps2w Watertight Insulgrip Plug, 3p4w, 200a 600v, Series 2

US $495.00

Camano Island, Washington, United States
Jan 29th

Open on mobile:
QR code

Product Specifications Product Type Service Style Standard Insulgrip Grounding Style Style II Device Plug Amperage 200A Voltage 250V DC/600V AC Poles and Wires 3 Pole, 4 Wire Terminal Accommodations #1 To #250 KCMIL copper wire only Cord clamp range 1.00" To 2.50" Replacement Interior Number IN4200MS2 Housing Aluminum Shroud Aluminum Lock Ring Epoxy Painted Aluminum Contact Carrier Thermoset Polyester Retainer Thermoset Polyester Terminal Screws Heat treated and Zinc Plated Steel Assembly Screws Stainless Steel (300 series) Gaskets Neoprene Cord Clamps Aluminum Grommet/Glands Neoprene Gland Cap Epoxy Painted Aluminum Cord Clamp Screws Stainless Steel (300 Series) Ground/Phase Sleeve Brass Ground Bracket Nickel Plated Spring Bronze Certification UL Listed, UL Standard 1682, UL50 and UL1010 (plugs only), CSA Certified to CSA C22.2 No. 182.1, No.94 and No. 159 (plugs only), UL Listed and CSA Certified Type 4X. Dielectric Withstand Voltage Withstands 3,000V AC Min. Max Working Voltage 600V AC RMS (i.e., minimum creepage and clearance distance of 6.4 mm, per UL 1682). Current Interrupting Certified for current interrupting at full rated current. Temperature Rise Max 30° C temperature rise at full rated current after 50 cycles of overload at 150% of rated current. Endurance Up to 1,000 connect and disconnect cycles at full rated current and voltage. Impact Resistance Per CSA C22.2 N0. 182.1 / UL1682 Cord Grip Retention Per CSA C22.2 N0. 182.1 / UL1682 Cord Accommodation Round portable service cords of diameters commensurate with the device rating as defined in UL Standard 62, CSA C22.2 No. 49 and the harmonized European Standards. Terminal Identification Terminals identified in accordance with UL1682 (1, 2, 3, Green). Product Identification Identification and ratings are a permanent part of the device housing. Moisture Resistance Type 3, 4, 4X per UL 50 and CSA C22.2, No. 94. Flammability UL 94V-0 and CSA C22.2 No.0.17 Operating Temperatures Maximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact, -25° with impact. Hazardous Locations Plugs Only- Class I, Division I & II, Groups B & C & D and Class II Division I & II, Groups F & G per UL 1010 & CSA 22.2, No. 459. Certifications UL Listed, UL Standard 1682, UL 50, and UL 1010 (plugs only) CSA Certified to CSA Spec. C22.2 No. 182.1, No. 94 and No. 159 (plugs only) UL Listed, CSA Certified Type 4X. Device Description The interchangeable product line, INSULGRIP pin and sleeve features metallic where you want it and non-metallic where you need it. Two different grounding styles are available. UPC Number 78358501148 Weight in LBs 11.6 Link to Drawing Library Click here for Library Link to PDF Catalog Click here for Catalog Configuration Dimensional Diagram

Condition:

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...

Brand

HUBBELL
