Genx 3d Reprap Controller - 4-axis, Usd, Marlin, Pcb Heated Bed

US $99.95

North Vancouver, British Columbia, Canada
Jan 29th

Open on mobile:
QR code

Overview This auction is for one GenX 3D RepRap turnkey controller. This is a brand new design from SOC Robotics, Inc. All functions necessary to control a 3D RepRap printer are on this board. GenX has four stepper motor controllers based on the A4983 driver, extruder heater Power Mosfet, heated bed Power Mosfet (14A), two 3A auxiliary fan PWM controls, uSD connector, USB 2.0 interface, three hybrid opto/mechanical limit switches plus two more mechnical limit switches, ATmega1284P processor (20MHz) running a ported version of Marlin (full source code available), auxiliary serial port (RJ11 connector) for connecting a touch screen DRO/Pendant, I2C port and ISP programming port. The board comes preloaded with Marlin with support for standard thermistors. The ATmega1284P comes preprogrammed with an stk500V2 bootloader activated by external jumper or directly from Marlin. GenX runs three different G Code controllers - Marlin, GRBL and SOC Robotics own GStep. Marlin and GRBL are both open source G Code controllers. SOC Robotics has ported both GRBL and Marlin to AVR Studio 6 in addition to the standard Arduino ports. GStep is proprietary to SOC Robotics and supports four axis control with both circular and linear interpolation. GStep turns GenX into a 4-axis controller for Milling machines such as a Sherline or Tag and lathes. With GRBL or GStep GenX functions as a four axis 2A/phase embedded G Code controller with two 14A Power Mosfets, two 3A Power Mosfet outputs and five limit switch inputs. This is the Rev 3 board with screw top terminals to handle PCB Heat Beds. The new design allows a seperate power supply to power the heat bed or one high current supply to power the whole board. This is an Open Hardware design and full schematics and layout is provided (see below). The board is professionally manufactured by SOC Robotics, Inc. in Canada. GenX Technical Brief (pdf): GenX Technical Brief GenX Preliminary Technical Manual (pdf): GenX Technical Manual GenX Marlin Arduino Port (zip): GenX Marlin Arduino V10 Port GenX stk500V2 Bootloader (zip): GenX stk500v2 bootloader v2.03 GenX Marlin Visual Studio 6 Port (zip): GenX Marlin V0.95 Visual Studio 6 Port (no uSD support yet) GenX GStep Hex file (.hex): GenX GStep hex file GenX GRBL AVR Visual Studio 6 Port (zip): GenX GRBL AVR Visual Studio 6 Port GenX Eagle Schematics (zip): GenX Eagle Schematics GenX Win USB Driver (zip): GenX Win Driver Technical Specifications ATmega1284P processor running at 20MHz with stk500V2 bootloader (AVRdude and AVR Studio4/5/6) A4983 bipolar driver with 1, 1/2, 1/4, 1/8, 1/16 microstepping modes supported Power Mosfet for Extruder heater with thermistor feedback Power Mosfet for Heated bed with thermistor feedback Optional precision thermistor 1.024V reference for high accuracy temperature measurement Three hybrid opto/mechanical limit switches Two additional mechanical limit switches uSD connector with full Marlin support built-in Two 3A fan control ports with PWM control Additional analog input with optional pads for third termistor intput Full Marlin Arduino port with enhanced commands such as program control of bootloader activation, PWM fan contro, etc. Jumper to allow USB to power board Dimensions 2.50x4.30in Warranty GenX scome with a 90 day warranty and a 7 day return policy. If not completely satisfied simply return the unit in the original packaging for a full refund (less shipping charges). Canadian customers will be charged 5% GST or applicable HST and BC customers 12% HST. This is a new unit direct from the manufacturer and includes warranty and technical support. After purchasing, pay instantly with your credit card through PayPal!
