Global Specialties 4001 Pulse Generator, 0.5 To 5 Mhz

US $238.00

Boca Raton, Florida, United States
Mar 6th

Open on mobile:
QR code

AUTHORIZED DISTRIBUTOR Global Specialties 4001 5 MHz Ultra-Variable Pulse Generator The 4001 is designed to permit precise tailoring of pulse repetition rates and duty cycles over a wide range through the independent setting of pulse width and pulse spacing. Both are continuously variable over seven decade ranges from 100 ns to 1 s, with outputs from 0.5 Hz to 5 MHz. Four front panel push-button selectable operating modes can be used to produce a pulse train or enable a single output pulse. Pulse duration is determined by width control. Use the 4001 as a missing-pulse detector, to trace digital logic flow, to analyze microprocessor programs, for testing radio control receivers, or many other applications requiring a precision pulse source. Features Independent settings of pulse width & spacing Outputs from 0.5 Hz to 5 MHz Four modes: run, triggered, gated, one-shot Symmetrical square wave outputs Complement output - inverts waveforms Variable output for CMOS circuits Product Description The model 4001 ultra-variable pulse generator is uniquely designed to permit precise tailoring of pulse repetition rates and duty cycles over a wide range through the independent setting of pulse width and pulse spacing. Both pulse width and pulse spacing are continuously variable over seven decade ranges from 100ns to 1s, with outputs from 0.5Hz to 5MHz. Its uncomplicated, rugged design and high quality components help ensure long and dependable service. Notable features include two simultaneous independent outputs (TTL and variable) with rise and fall times less than 30nsec, 20nsec TTL compatible leading-edge sync pulse output, and independent pulse width and pulse spacing controls (both selectable from 100nsec to 1sec). Four front panel push-button selectable operating modes with one-shot push-button can be used to produce pulse train or enable a single output pulse. Pulse duration is determined by width control. All of these features, plus an uncomplicated front panel layout all add up to an effective solution to a wide range of pulse source problems. The 4001 pulse generator with its many features and ease of operation make it a welcome addition to any lab. Some of the varied uses for the 4001 are as a missing pulse detector, tracing digital logic flow, analyzing microprocessor programs, or testing radio control receivers. The 4001 can also be used in audio testing and for many other applications requiring a precision pulse source. Variable output for CMOS circuits. Sensitivity: trigger/gate, DC couples, BNC connector, TTL compatible 40nsec wide, >2.4Vpk or sine wave >1.7Vrms. Outputs: 3 outputs, DC coupled, BNC connector. VAR impedance: constant 50 ohms. VAR amplitude: 0.5-10V into open circuit, 0.25-5.0V driving 50 ohms, variable with Amplitude control, rise/fall time less than 30 nsec. TTL drive: standard TTL levels, buffered to drive up to 40 TTL loads, rise/fall time less than 20 nsec.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	GLOBAL SPECIALTIES
Country/Region of Manufacture	Taiwan
MPN	4001
