Gm328 Multi-use Transistor Diy Kit Signal Generator + Acrylic Case

US $22.30

Shenzhen, China
Aug 9th

Open on mobile:
QR code

GM328 Multi-use Transistor DIY Kit Signal Generator + Acrylic Case Description: Digital LCD display for easy readings, can display measured data and graphics. Automatically detects NPN and PNP transistors, FET, diodes, dual diode, thyristor, SCR, automatic identification of the transistor pinout. Can be used as signal generator and frequency meter: frequency range from 1Hz-2MHz and can generate 1%-99% PWM(pulse width modulation) signals. Rotary switch control, a key measurement for convenient use. Automatic shutdown, shutdown current is only about 20nA. Main chip is the DIP, easy for electronic enthusiasts to DIY or update the main chip. Test NPN and PNP transistor common-emitter current amplification factor, the base-emitter threshold voltage, off the collector - emitter leakage current. Support 2 resistors measurement, show its positive and negative, on-state voltage. Automatically test the pins of a component and show on the display. Measure FET gate threshold voltage and gate capacitance. For the following 2100 resistor while measuring its inductance measuring range from 0.01mH - 20H. Specification: Display: 160x128 LCD Power Supply: 1 x 9V Battery(not included); DC 6.8-12V Current: Approx. 30mA Resistance Measurement: Max. 50M Resistance Resolution: 0.01 Capacitance Measurement: 25pF~100mF Capacitance Resolution: 1pF DC Voltage Measurement: Up to 50V Screen Size: 3.7 x 3cm / 1.45 x 1.18 inch PCB Size: 7.8 x 6.2cm / 3.1 x 2.44 inch Product Weight: 66g / 2.3oz Case Material: Acrylic Case Size: Approx. 96 x 82 x 28mm / 3. 8 x 3.2 x 1.1 inch (L x W x H) Package Includes: 1 x Full Assembled Transistor Tester 1 x DIY Acrylic Case Note: Color maybe slightly different due to different monitor. The above size is measured by hand, please allow slightly difference. Thanks ! Shipping And Handling Policy The buyer is responsible for any applicable import duties and local taxes. Please verify with your customs before making your purchase. Please verify your address during checkout. We are not responsible for any wrong or undeliverable addresses. People always bought together with

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
MPN	Does Not Apply
Color	as described
Material	as described
Country/Region of Manufacture	China
Size	96 x 82 x 28mm
UPC	Does not apply
ISBN	Does not apply
EAN	Does not apply
