i000000 GM328 transistor tester/ ESR table/LCR table/frequency meter/square wave generat Click Photos to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Click to Enlarge Description GM328 transistor tester/ ESR table/LCR table/frequency meter/square wave generator I. Overview 1 using the 2014 version of the latest V1.11 software, using M328 chip,, more features, in addition to the basic functions, as well as extensions. 2 micro-controller uses 8MHz external crystal, the measurement accuracy is better. 3 affect the accuracy of the relevant resistance using a thousandth of a metal film resistors, and the remaining one percent is also used metal film resistors. 4.LCD using 12864 LCD screen that can display measured data and graphics. 5 main chip dual in-line and with a socket, ideal for electronics enthusiasts upgrade or replace the chip. 6 uses 9V laminated battery. 7 All components are made of high quality genuine. LCD screen for low power backlit screen, the backlight current of about 2mA, so after boot time has backlighting for easy use in the dark. 8 Dimensions: 80 (W) X 105 (high) X22 (depth) mm. 9 Weight: about 70 grams. The Working Current: 9V voltage, stable operating current of about 20mA. A, the basic function 1 one-button operation, automatic shutdown. 2 shutdown current is only about 20nA. 3.Adopt 8MH crystal. 4 can automatically detect NPN, PNP bipolar transistors, N-channel and P-channel MOS FET, JFET, diodes, dual diode, thyristor small power unidirectional and bidirectional thyristor. 5 automatic identification pin arrangement of components. Current amplification factor and base 6 measuring bipolar transistor - emitter threshold voltage. 7 can be extremely via the base - emitter threshold voltage and high-current amplification factor identification Darlington transistors. 8 protection diodes can detect bipolar transistors and MOS transistors. 9 measuring MOS FET gate threshold voltage and gate capacitance. 10. can simultaneously measure two resistors and resistor symbol is displayed. 4-digit display with decimal value 11 on the right. Resistance symbol is displayed on both sides of the pin number. So you can measure the potentiometer. If the potentiometer wiper position will not be transferred to a certain extreme, we can distinguish between the middle and both ends of the pins. 11 resistance measurement resolution is 0.1 ohms, 50M ohms can be measured. 12 can measure capacitance. Capacitor symbol is displayed on the right display values can be displayed with a decimal four values. Can measure the capacitance of 30pF-100mF resolution 1pF. 13.2uF more capacitors can measure the value of the equivalent series resistance ESR. The two values can be displayed with a decimal, resolution 0.01 ohms. Two diodes 14 can be displayed in the correct order and a diode symbol, and gives the diode forward voltage. 15.LED is detected as a diode, a higher forward voltage. Combo of the LED is recognized as two diodes. 16. reverse breakdown voltage is less than 4.5V zener diode can be identified. 17 can measure a single diode reverse capacitance. If the connection base and collector of the bipolar transistor or the emitter of a pin, or the reverse can be measured or the collector junction capacitance of the emitter junction. 18 with a single measurement can get connections rectifier bridge. 19 Although the measurement limit capacitance of 25pF, but you can be measured by the measured capacitance with a known volume of at least 25pF capacitor in parallel, then the measure will result in parallel capacitance obtained by subtracting B. extensions (via menu selection, and the user may want to add a few components, suitable for DIY) 1 can measure 1Hz-2MHz frequency. Above 25kHz resolution of 1Hz, the low-frequency measurements using the cycle, the resolution can go to 0.001MmHz. 2 can measure DC voltages below 50V. 3 can produce a square wave signal of 1Hz-2MHz. 4 can generate a fixed frequency pulse width but variable pulse wave, short key width by 1% increments, the longer the key width by 10% increments. 5. Can be activated by the individual capacitance and ESR menu functions, ranges 2UuF-50mF, since the amplitude of the measured signal is only 300mV, it is possible to measure the road. (Translation: due to non-4-wire measurement, the measurement lead resistance may lead to large errors, particularly small ESR measurements). 6 by adding a rotary coding switch, convenient menu item selection. Special note: Motherboard compatible 1602 character LCD and 12864 dot matrix LCD, as long as the update to the corresponding program and insert the corresponding display.Adopted into components, single chip microcomputer with socket, very suitable for lovers of DIY. Before measuring the capacitance, the capacitor must be discharged, otherwise very likely damage the meter include: 1 PC More information, you can send message to us.Thanks O(∩_∩)O~~ Sweet Notice If you have any problems with our items,pls contact with us .We can solve it for you perfectly. Pls trust us.Thanks. Feedback : We would appreciate receiving your 5 stars positive feedback.If there's any dissatisfaction with your parcel ,pls contact with us before you leave the feedback .We can solve it for your perfectly.Thanks for your understanding and help. Shipping time : If you haven't get your parcel within the expected date,Pls contact with us directly .We can ensure solve it for you . Pls trust us .We need your support. Thanks .Yours Sincerely. Country Shipping Time Refund or Resend 80% 12% 5% United States United Kingdom Australia /Canada 10-20 working days 25 working days 27 working days >27 working days Singapore Other Asia country 15-25 working days 28 working days 32 working days >32 working days Germany /France Austria /Netherland Poland 20-30 working days 33 working days 36 working days >36 working days Spain Russia 25-35 working days 37 working days 40 working days >40 working days Others 25-35 working days 37 working days 40 working days >40 working days Return Policy : 1. All items are checked and packed in good condition before dispatch. 2. If you find any defect in our items, please contact us within 14 days of receipt item. 3. Return items must not be used. 4. Buyer is responsible for all return shipping charges. We will return all your money except the shipping and handling fees or make exchange for you after we receive your return items. Please do not ship the item back to us without our confirmation. Thanks Payment and Shipping PAYMENT TERMS: We accept paypal .Credit card payments must be made through PayPal. SHIPPING TERMS: Our work time is during 8:00 am -5:30 pm ,from Monday to Friday (GMT+8 ).We will post your order within 24 hours (Except some special orders ,such as the handmade case). Maybe we are out of office during the weekend, so pls wait for our reply patiently. We will reply all your problems as quickly as we can. Thanks for your understanding. inkfrog terapeak
