GME Pattern Generator PG-16A, US $85.00 – Picture 0
GME Pattern Generator PG-16A, US $85.00 – Picture 0

Gme Pattern Generator Pg-16a

US $85.00

  • Charlotte, North Carolina, United States
  • Mar 5th
Open on mobile:
QR code
GME Pattern Generator PG-16A.  Unused except to test before posting.  Works great! Model PG-16A Pattern Generator is the perfect tool for those who need to quickly and easily troubleshoot, test, and align NTSC television, PC and Mac computer monitors. It features a wide range of testing resolutions for computer monitors ranging from 640x350 to 1600x1200. The video patterns generated by the PG-16A provide accurate and comprehensive TV/Monitor troubleshooting and testing. User friendly interface for easy operation. The model PG-16 can quickly and easily troubleshoot, test, and align TV and popular PC, Mac computer monitors. · Testing PC: VGA: 640x 350, 640x400, 640x480, SVGA: 800x600, 8514A: 1024x384, VESA: 1024x768, 1280x1024, 1600x1200 · Testing Mac: 640 x 480 Composite Sync, 640 x 480 Sync. on Green, 640 x 480 Separate Sync, 830 x 624 Composite Sync. · Video Patterns: color bars, Cross hatch, Dots, circle, Color raster &Windows. · Two Video connector for monitor: Analog 15-HD and Analog 15-DB · Two video connector for TV: Composite video and S-video · TV testing features: Scanning system: interlace; Composite video: 1.0V p-p into 75 Ohms; S-video: Chrominance output 0.6v p-p into 75 ohms Luminance plus Sync Output: 0.8V p-p into 75 Ohms · Powered by a 9V battery or an external AC adapter (not included) · Dimension: 3.8”x 5.7” x 1.5”
“Never used. Open box.”
Brand GME
Model PG-16A
