Goodyear Hydraulic Hose 1-1/4" 2-wire 1,820 Psi - 50' Rolls

US $460

  • West Palm Beach, Florida, United States
  • Jun 18th
New unopened Goodyear 2-Wire Hydraulic Hose 50' Rolls.  Discounts and free shipping available for large orders. For questions or custom lengths please call us @ 561-844-3699 Overview Family Part Number GR2SN  Hose Description SAE 100R2AT/2SN Pressure Level High Pressure Meets or exceeds the performance requirements of: SAE 100R2AT, DIN 20022 2SN, EN 853 2SN Application High pressure hydraulic oil lines used in construction, machine tool and agricultural applications using petroleum or water based hydraulic fluids Temp range -40°F to 212°F (-40°C to 100°C) Construction Inner Tube Nitrile Reinforcement 2-wire braid Cover Compound Neoprene Operating Details Hose ID in. 1 1/4 DN Dash Size 31 Hose OD in. 1.877 mm. 47.7 Max. Working Pressure psi 1820 mpa 12.5 Min. Burst Pressure psi 7280 mpa 50.2 Min. Bend Radius in. 16.5 mm 419 Weight/foot (lbs) 1.2938
