Gorton 8D, 8-1/2D, & 9J Milling Machine & Duplicators Op & Parts Manual *1295, US $380 – Picture 0
Gorton 8D, 8-1/2D, & 9J Milling Machine & Duplicators Op & Parts Manual *1295, US $380 – Picture 0

Gorton 8d, 8-1/2d, & 9j Milling Machine & Duplicators Op & Parts Manual *1295

US $380

  • Goddard, Kansas, United States
  • Jun 1st
Open on mobile:
QR code
 Gorton  8D, 8-1/2D, & 9J, Milling Machines & Duplicators   Operators and Parts Manual   For models: Gorton 8D, 8-1/2D, 9J Vertical Milling Machines               Gorton 8D, 8-1/2D, 9J Duplicators               Gorton 8D Universal Milling Machine Description: This is an Operators Manual for the Gorton Vertical & Duplicating Milling Machines Models 8D, 8 1/2D, & 9J, and also the 8D Universal Milling Machine.  It contains sections on Operation, Lubrication,   Adjustments, Die Mold Cutting, Models for Die and Mold Duplicating, Cutters for Die and Mold Work, Grinding Single Flutes, Cutters with Gorton Cutter Grinders, and a Cutter Speed Chart.  It has a complete set of cutaway parts views and part numbers.  The manual has 28 pages.   To inspect the quality of the manual,  and to view select pages,  please click on the gallery images above to enlarge. Includes sections on: Unpacking and Erecting Lubrication Adjustments Operation Die & Mold Cutting Models for Die & Mold Cutting Cutters for Die and mold Cutting Grinding Single Flutes Cutters with Gorton Cutter Grinders Cutter Speed Chart Assembly Drawings with Part Numbers Number of pages: Approx 28 Condition of original:   Very Good Publication date: N/A Publication No.: 1410 Added Notes:   Due to others making copies of these manuals for resale, I have lightly watermarked select pages to discourage this practice. About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop. Questions? Email: eugene@fabersurplus.com Phone: 316-210-4079 after 11:00 am Central Time Ships USPS First Class Free or Upgrade to Priority Mail for faster delivery. Reprinted from original manual using high quality 24lb paper and comb binding. Covers are printed from 65lb cardstock for extra durability. Sales tax charged for Kansas sales. See my for more manuals.  Be sure to add me to your favorites list!
