Gowoops 4 Axis Cnc Control V3 Cnc Engraver Shield Expansion Board + 4pcs Mks ...

US $250

US, United States
Nov 6th

Open on mobile:
QR code

Gowoops 4 Axis CNC Control V3 CNC Engraver Shield Expansion Board + 4PCS MKS DRV8825 Stepper Motor Driver Module + 4 PCS Aluminum Heat Sinks for Arduino 3D Printer Kit Reprap Product Features Latest Arduino CNC Shield Version 3.0, open source firmware that runs on an Arduino UNO that turns G-code commands into stepper signals PWM Spindle and direction pins. 4-Axis support. Runs on 12-36V DC, 2 x End stops for each axis (6 in total). The DRV8825 features adjustable current limiting, overcurrent and overtemperature protection, and six microstep resolutions (down to 1/32-step). The DRV8825 operates from 8.2 - 45 V and can deliver up to approximately 1.5 A per phase without a heat sink or forced air flow (rated for up to 2.2 A per coil with sufficient additional cooling The DRV8825 stepper motor driver carrier is a breakout board for TI's DRV8825 microstepping bipolar stepper motor driver. Product Specifications Brand Name: Gowoops Product Dimensions: 2 x 1.2 x 0.8 inches Item model number: ZZAD200200 Color: CNC Board + 4pcs DRV8825 Step Motor Number of Items: 5 Manufacturer Part Number: ZZAD200200 Shipping Information: View shipping rates and policies Date First Available: August 8, 2016 Why you Should Buy from Us? Trusted Seller, Great Feedback Quick Shipping and Tracking HUGE Discounts Excellent Returns Policy The BEST Customer Service Shipping & Returns We Ship Worldwide! 14 Day Money Back Return Policy Items Ship within 24-72 Hours Shipping process begins as soon as you order. We cannot cancel orders. Our goal is FAST delivery! Product Description Color:CNC Board + 4pcs DRV8825 Step Motor CNC Shield Board: Latest Arduino CNC Shield Version 3.0 GRBL 0.9 compatible. (Open source firmware that runs on an Arduino UNO that turns G-code commands into stepper signals) PWM Spindle and direction pins 4-Axis support (X, Y, Z , A-Can duplicate X,Y,Z or do a full 4th axis with custom firmware using pins D12 and D13) Coolant enable Jumpers to set the Micro-Stepping for the stepper drivers. (Some drivers like the DRV8825 can do up to 1/32 micro-stepping) Compact design. Stepper Motors can be connected with 4 pin molex connectors or soldered in place. Runs on 12-36V DC. (At the moment only the DRV8825 drivers can handle up to 36V so please consider the operation voltage when powering the board.) Please note that this is an unassembled kit and Basic soldering skills are needed DRV8825 Stepper Motor Driver Module: Simple step and direction control interface Can interface directly with 3.3 V and 5 V systems Over-temperature thermal shutdown, over- current shutdown, and under-voltage lockout Short-to-ground and shorted-load protection 4-layer, 2 oz copper PCB for improved heat dissipation Exposed solder-able ground pad below the driver IC on the bottom of the PCB Six different step resolutions: full-step, half-step, 1/4-step, 1/8-step, 1/16-step, and 1/32-step Adjustable current control lets you set the maximum current output with a potentiometer, which lets you use voltages above your stepper motor's rated voltage to achieve higher step rates 45 V maximum supply voltage Built-in regulator (no external logic voltage supply needed) Module size, pinout, and interface match those of our A4988 stepper motor driver The max running currency: 2.5A Size: 1.5mmX2mm Package includes: 1 x CNC Shield Board 4 x DRV8825 Stepper Motor Driver Module 4 x Aluminum Heat Sink Thank You For Your Business!
