All items are sold as is without warranty unless specifically stated in the posting. This does not mean that the unit doesn’t work, only that we have not tested or checked it out. This may also mean that we are not knowledgeable in this specific item. The Item may vary from picture as manufacture may change model appearance. MHZ ELECTRONICS INC. - CALL Brent - 1-866-MHZ-ELEC MHZ ELECTRONICS INC. - CALL Brent - 1-866-MHZ-ELEC MHZ ELECTRONICS INC. - CALL Brent - 1-866-MHZ-ELEC MHZ ELECTRONICS INC. - CALL Brent - 1-866-MHZ-ELEC Granville-Phillips 303007 Series 303 Simultaneous IG Vacuum Process Controller comes with what you see in the pictures. If you don't see it, you probably won’t get it. Specifications are from manufacturer and may vary slightly due to upgrades, options, or revisions this unit may or may not have. Discontinued – Replaced by 307 Series 307 Series Suggested List Price: $1,395.00+ (OEM 03/27/09 MQF) Catalog Number: 303007 Serial Number : 1849 Manufacture Date : A8 Options : Analog & Convection w/ Cooling Fan Electrical : 115V, 50/60Hz, 3.0A SB Copy of the User Manual is Included. Equipment Description: The Series 303 Vacuum Process Controller (VPC) is a programmable, microprocessor controlled vacuum system controller. The basic VPC operates two ionization gauge tubes over the range from 5 x 10 to 1 x 10 Torr. There are two basic VPC models; VOCA and VPCB. VPCA sequentially operates two ionization gauge tubes, while VPCB is configured to simultaneously operate two ionization gauge tubes. Both VPC and VPCB front-panel controls and indicators are identical and allow the operator to program gauge tube sensitivity, electron bombardment degas power, degas time duration, gauge tube filament overpressure trip, direction/rate of change arrows, two-or-three-digit pressure readout, and security of programs against change. Also a control is provided for maximum emission current selection and indicators for leak testing and gauge tube filament circuit deterioration warning. The operational capability of a basic VPC can be upgraded by the installation of plug-in option cards. A VPCA or VPCB can be ordered with the desired options installed or the user may order and easily install the desired plug-in options. Eight card slots are provided for installation of the option cards. Installation procedures for the option cards are provided in Chapter 2 of the User Manual. Specifications: Electrical Voltage: 90-110/105-125/195-235/210-250 VAC rear panel selectable Frequency: 50Hz or 60Hz Power: 450W (maximum) Environmental Operating Temperature: 0 to 40°C (32 to 104°F). Warranted specifications given at 25°C ± 5°C. Physical Dimensions: 19W x 3.5H x 18D (48.3 x 8.9 x 45.7cm) Weight: 25lbs (11.6kg) not shipped Gauge Type: Baynard-Alpert type, or evquivalent, ionization gauge Pressure Range: 5 x 10 to 1 x 10 Torr; 7 x 10 to 1.3 x 10 mbar; 7 x 10 to 13Pa Gas Type: Direct reading for air, N2 or Ar. By altering the tube sensitivity in the N2 mode, other gas types can be measured directly. Accuracy of electronics measurement: Typically ±2% of pressure reading over the range 10 to 10 Torr (mbar) or 10 to 10 Pa Resolution of Ionization Guage (IG) Readout: ±0.1% of full scale in each decade, over the range (IG) readout 10 to 10 Torr (mbar) or 10 to 10 Pa; ±1% of full scale in the 10 Torr (mbar) or 10 Pa range; ±10% of full scale in the 10 Torr (mbar) or 10 Pa range Display Update Time: 0.5 second maximum for all ranges Programmable IG Tube Sensitivities: 0.1 to 99.9/Torr; 0.1 to 99.9/mbar; 0.001 to 0.999/Pa; Factory Set at 10/Torr Emission Current: User programmable to maximum values of 1, 2, 4 or 10mA. Factory set at 4mA. Controller selects one of the following constant emission currents, subject to the maximum value programmed, to optimize performance at a given pressure 0.01, 0.02, 0.04, 0.1, 0.1, 0.4, 1, 2, 4, 10mA. The emission can be fixed to the selected maximum value. This will limit pressure measurement range. Collector Potential: Zero V referenced to system ground Grid Potential: 180 ±10VDC referenced to system ground (adjustable) Filament Voltage: 2.0 to 8.5VAC RMS Filament Current: 6.0A RMS (maximum) Filament Bias: 30 ±4VDC referenced to system ground Degas Power: Electron bombardment. 5 to 80 watts, programmable in 5 watt steps. Power can be displayed during degas. Degas Pressure: Must be less than 5 x 10 Torr. Approximate pressure can be displayed during degas. Time: Programmable from 1 to 999 minutes, in one minute steps, or manually or remotely timed. Degas time remaining can be displayed. Start: Soft start – Start manually or with remote signal. Stop: Manually or remotely timed. Grid Potential: 500VDC effective. Measured with respect to filament. Emission: 10 to 160mA Input Functions: IG1 On/Off, IG2 On/Off, Degas 1 On/Off, Degas 2 On/Off Current: 1mA to ground Contract Form: Single pole, double throw Contact rating: 2 @ 250VAC resistive load For More Pictures Please Click the Following: Picture 2 Picture 3 The charge for freight will be determined by the destination upon the ending of the auction. There will be a packing fee on larger and heavier items it will be determined by the size and the care that has to go into packing an item. Most of the time, people are impressed with the job we do because we customize our own skids for larger items and we take the utmost care to provide a safe and cozy journey for your item. We strive to make our customers happy and want you to feel that we have treated you with the ultimate respect. If you have any questions please call Brent at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. 05/06/09 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
