Graphtec Fc7000-130 Plotter

US $1,700.00

Carpentersville, Illinois, United States
Mar 7th

Open on mobile:
QR code

Maximum cutting area, 54" x 164', Compatible media with = 2.9 in to 60.2 in, Maximum auto cross cutting width = 59", Dimensions (W x D x H on stand)=73.2” x 28.1” x 47.6”, 112lbs Automatic sheet cutter maximum thickness 11 mil including release liner Maximum media thickness 59.1 mil Maximum cutting speed 58.5 in/s (1485 mm/s) (45° direction) Programmable axial cutting speeds 0.4 to 41.3 in/s in 105 steps (10 to 1050 mm/s) (from PC operation) Maximum axial acceleration 4.0 G (39.2 m/s?) Programmable cutting force 20 g to 600 g (0.2 N to 5.88 N) in 40 steps Mechanical resolution 0.0002 in (0.005 mm) Programmable resolution GP-GL™: 0.0004 in (0.01 mm); HP-GL® emulation: 0.001 in (0.025 mm) Repeatability*1 0.0039 in/80 in (0.1 mm/2m) travel or better Blade types 0.9 mm 45°, or 1.5 mm 45° or 30° Graphtec SuperSteel, 1.5mm ceramic or 1.5mm sapphire tip blades Pen types Water/oil-based fiber tip, water/oil-based ballpoint, Fine Point Sharpie (with optional pen adapter) Media types Cast/calendared vinyl, window tint, paint protection, PET film, EC film, diamond grade and high Intensity reflective, laminate film, vinyl banner, Amberlith™, Rubylith™, paper, decals, labels, garment vinyl, flex, flock, twill, sandblast mask Pouncing function Optional 1.2mm Pouncing tool Perforated line cutting Perforated line settings (Control panel selectable) Inter faces RS-232C serial, USB2.0 (compatible with USB 1.1) Data buffer 2 MB Command set GP-GL / HP-GL® (control panel selectable) Control panel display 20 digits by 4 line LCD. Menu display and soft keys Automatic Registration Mark Sensor Advanced ARMS (detects 2, 3, 4 Point marks, intermediate segments, and multiple embedded marks for maximum flexibility. ARMS automates first mark detection, and rescans subsequent marks as needed to apply Dual Axis Error Correction to compensates for printer skewing or distortions. Media Supply mechanism Brake system and reverse tension mechanism adjusts the media upon loading, Work surface Guide marks to align media Media Auto Pre-Feed Automatic media pre-feed unwinds and feeds roll media to the length specified in the cutting data file. Tangential Control Mode Standard Input Power Requirement 100-240V AC, 50/60 Hz; auto switching, 120 VA maximum Power Consumption Operating environment 50° to 95°F (10° to 35°C), 35% to 75% RH (non-condensing) Recommended Environment 60° to 90°F (16° to 32°C), 35% to 70% RH (non-condensing) Does not include basket

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Graphtec
Country/Region of Manufacture	Unknown
Model	FC7000-130
