Gratten Atf20b Dds Signal Function Waveform Generator 20mhz 100msa/s

US $3000

Canton, China
Jun 9th

Open on mobile:
QR code

The GRATTEN ATF20B DDS Signal Function Waveform Generator 20MHZ 100MSa/s is an exceptional testing solution with outstanding performance and system features. With Direct Digital Synthesis (DDS) technology and a simplified front panel design, our product offers ease of operation and observation with its dual-language TFT display interface in English or Chinese. Moreover, frequency range and resolution are precisely calibrated with 40mHz to max frequency for sine and 40mHz to 1MHz for other waveforms. Our amplitude accuracy is В± (1%+2mVrms), with a high impedance line that ranges from 2mVpp to 20Vpp across different frequencies, and we have a TTL waveform rise/fall time range of 20ns. Our waveform generator boasts high-frequency resolution and stores up to 40 sets of user parameters with 32 kinds of standard or pre-installed fixed waveforms. Our product has multiple modulation functions, including FM, FSK, ASK, and PSK, and comes with frequency sweep, amplitude sweep, and burst functions. Our product's output A characteristics come with 32 kinds of waveform types such as Sine, Square, Triangle, and Pulse, among others, with a waveform length of 1024 points. With a sample rate of 100 MSa/s and an 8-bit vertical resolution, our generator also comes with harmonic rejection, total distortion, rise/fall time of square, overshoot, and square duty cycle features. Trade_Spotting is a reputable online brand that specializes in offering development boards and professional test equipment. As a reliable eBay seller, we directly source from SainSmart's manufacturing before thoroughly testing and packing our products. Our generator counts the frequency, period, amplitude RMS value, or peak-to-peak value with over-voltage, over-current, output short-circuit, and reverse voltage protections to ensure high reliability. Our system uses VLSI components and surface mount technology, which are backed up by optional configurations such as RS232 interface, frequency counter, and power amplifier. Our product comes with a power supply of AC220V (1В±10%) / AC110V (1В±10%), and its power consumption is less than 45VA, with an operating temperature of 0В°C to +40В°C and an operating humidity of 80% R.H. Our system's keypad and rotary knob operation make it easy to use, and it comes with a TFT display, weighing

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Gratten
MPN	Does not apply
UPC	Does not apply
