GRAYHILL ROTARY SWTCH M3786/4-0639 42M3601204N NOS, US $19.99 – Picture 0

GRAYHILL ROTARY SWTCH M3786/4-0639 42M3601204N NOS, US $19.99 – Picture 1

GRAYHILL ROTARY SWTCH M3786/4-0639 42M3601204N NOS, US $19.99 – Picture 2

Grayhill Rotary Swtch M3786/4-0639 42m3601204n Nos

US $19.99

Axton, Virginia, United States
Jan 29th

Open on mobile:
QR code

ONE NEW OLD STOCK GRAYHILL ROTARY SWITCH PART# M3786/4-0639 , 42M36-012-04N, THANKS FOR LOOKING5930-01-178-8738 5930 011788738 Switch, Rotary 02134 5930-01-178-8738 Features MRC Parameter Characteristics AASA Thread Length 0.437 inches nominal single mounting facility ABFE Hazardous Locations/Environmental Protection Explosion proof ABHP Overall Length 1.899 inches nominal ABNB First Flat Length 0.250 inches nominal single actuator ABNC Flat Height 0.216 inches nominal single actuator ABWV Shaft Diameter 0.250 inches nominal single actuator ABXF Shaft Length 0.437 inches nominal single actuator ADAV Overall Diameter 1.000 inches minimum and 1.306 inches maximum AEFP Nonturn Device Radius 0.375 inches nominal at 3:00 o'clock AFBH Individual Section Quantity 1 AFDC Nonturn Device Type Tab at 3:00 o'clock AFGA Operating Temp Range -65.0/+85.0 deg celsius AJZE Switch Contact Basic Design Nonpile-up symmetrical AKPX Pole Quantity 2 single section front AKPY Throw Quantity 4 single section rear AXGY Mounting Method Threaded bushing single mounting facility CQJX Nominal Thread Size 0.375 inches single mounting facility CQMK Contact Voltage Rating IN Volts 115.0 ac at sea level CQMK Contact Voltage Rating IN Volts 28.0 dc at sea level CQRQ Shaft Flat/Slot Angular Location 216.0 degrees from nonturn device single actuator CQTH Rotor Through Connection Quantity 2 single section CRJH Switch Actuator Indexing Position Quantity 4 single actuator CRSJ Shaft Type Round, flatted single actuator CSCF Terminal Type Tab, solder lug CSHW Contact Switching Action Breaks before makes single section rear CSLC Switch Actuator Positioning Increment 36.0 degrees single actuator CSMW Detent Rotational Torque Range +0.500/+2.500 inch-pounds single actuator CTDN Switch Actuator Stop Device Type Fixed stop single actuator CTHF Contact Load Current Rating 250.0 milliamperes resistive load dc at sea level and 100.0 milliamperes inductive load dc at sea level CTHF Contact Load Current Rating 75.0 milliamperes resistive load ac at sea level STYL Style Designator Tap, circular, bushing mount TEST Test Data Document 81349-MIL-S-3786 specification (includes engineering type bulletins, brochures, etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "nominal", etc.). THSD Thread Series Designator Unef single mounting facility ZZZK Specification/Standard Data

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	GRAYHILL
MPN	M3786/4-0639
Model	ROTARY SWITCH
