Grimm 1.108 Aerosol Spectrometer Portable Dust Monitor Particle Counter

US $1600

Denver, Colorado, United States
Jun 9th

Open on mobile:
QR code

Being offered is a Grimm model 1.108 Portable Dust Monitor. It is in good condition, and passes Calibration Tests. Includes hard case, power supply and battery pack. Battery pack condition is unknown. This state-of-the-art aerosol monitoring system from GRIMM is the latest instrument in our renowned line of high speed counters. With a resolution of 1 count/liter, the aerosols are collected on a removable 47 mm Teflon filter for gravimetric or chemical analysis. This unique dual technology is incorporated in all GRIMM real-time particle size analyzers. The results can also be analyzed by our 1.177 GRIMM Software program and displayed as: particle counts in 15 channels mass distribution in 15 classes environmental PM-10, PM-2.5 and PM-1 occupational as inhalable, thoracic, respirables (alveolics) temperature, humidity and wind speed changes A random sampling head collects the dust in accordance to the Johannesburger Convention and leads the particles directly into the optical chamber with the laser. There each particle is counted and classified by size and the concentration is proportional to the collected time. Results can be continuously given in one second or longer, up to one minute in intervals. For use outside, a special weather housing was developed so the unit can be used in rain, but without being sensitive to the humidity (particle condensation). This system does not heat the sample pipe as heating the sample pipe will simply drive out all the semi volatiles from the air and lead to wrong results. Key Features Each GRIMM Model 1.108 is hand crafted one at a time to the highest engineering standards and in accordance to the most current ISO 9000 requirements. Like all our 1.100 series instruments, the Model 1.108 has optical technology for real-time monitoring as well as a precise volume controlled air flow with an integrated PTFE filter, so all the dust measured optically can be analyzed at a later date for the composition and the gravimetric mass correlation. Some of the additional features: Displays real time data in as little as six seconds. Portable, weighing only 2.4 kg (5.4 lbs.) with re-chargeable battery. 15 different size channels from 0.30 µm to 20 µm LCD displays results in particle counts or mass distribution. Auto zeros and performs system self-diagnostics at the start of each analysis. Removable 47 mm PTFE filter for optional gravimetric and/or chemical analysis of residue. Removable data storage cards. Data cards can hold up to one year of data. Warning limits can be preprogrammed into the unit with an audible alarm. RS 232 serial port for optional computer interface. Analog inputs for optional environmental sensors. Product Specifications Particle Size 0.30/0.40/0.50/0.65/0.80/1.0/1.6/2.0/3.0/4.0/ 5.0/7.5/10/15/20 µm Count Range 1 to 2,000,000 counts/liter Mass Range .1 to 100,000 µg/m3 Size channels 16 channel sizes, mass in µg/m3 and particle counts/liter Sensitivity 1 particle/liter Sample Flow Rate 1.2 liters/minute, flow controlled Reproducibility +/- 2% PTFE Filter Size 47mm Operating Temperature Range 4oC to 45oC Physical Parameters Dimensions 24 x 12 x 6cm (9.5 x 5 x 2.5") Weight 2.4 kg (5.4 lbs.) Input/Output lx RS 232, 3x Analog Power Requirements Battery or 110/220 VAC with external power supply The following options and accessories are available: Omni-directional, lsokinetic and clean room Sampling Heads Stainless Steel or Poly-Resin Housing for outdoor operation Temperature, Humidity and Windspeed sensors. Software Options and Data Presentation The standard LCD readings are: Counts in particles/liter Mass as µg/m3 Date and Time Up to three sensor inputs Location Battery Status Filter Status Various system diagnostic and instrument status. GRIMM’s software is fully compatible with WINDOWS ™95 , 2000, ME, XP and NT. Data can be presented in the following formats: Environmental Mode: PM 10, PM 2.5 and PM 1 conventions. Occupational Mode: lnhalable, Thoracic and Respirable (alveolic). Mass mode: µg/m3 in 15 size channels Particle counts: particles/liter in 15 sizes
