Gripper 3.0 For Parallax Small Robots

US $113.85

Swanton, Vermont, United States
Jul 20th

Open on mobile:
QR code

Description Gripper 3.0 for Parallax Small Robots CNC-machined end-effector design Provides durable and lightweight performance Single-servo actuates, grab-and-lift motion Compatible with Parallax small robot chassis Easy to assemble The Gripper 3.0 for Parallax Small Robots is a precision CNC-machined end-effector design for all of Parallax’s small robots. The single servo actuates the grab-and-lift motion with only a small amount of linear movement. The tension between the Gripper plates is determined by a torsion spring which also holds the plates down until the Gripper has closed on the object, with remaining servo motion lifting the object from the surface. The programmer only needs to determine the servos opened/lowered, closed/raised position, and the rate at which the transition occurs without consideration of the width of the object (provided it fits within the Gripper’s paddles). The kinds of objects the Gripper can easily pick up include 3D-printed cylinders, small wooden square blocks, and most lighter things about 1-½" in diameter and up to an ounce in weight. Adding foam tape to the paddles (included) and a small counterweight to the chassis (not included) may increase lift capacity. Take these parameters into consideration when designing autonomous robot contest rules. Specifications Power Requirements: 4-6 VDC Communication interface: PWM signal What's Included CNC machined aluminum parts 1 x Hinge 1 x Base 2 x Arms 2 x Idler Gears 2 x Fingers 2 x Paddles Laser-cut parts 2 x Gear Plate Hardware parts 9 x 4-40 " Panhead screws 1 x 4-40 nut 9 x 4-40 nylon locknuts 6 x 4-40 ¼" Panhead screws 4 x 4-40 3/16" flathead screws 1 x 4-40 1-¼" Panhead screw 2 x #4 stainless steel washers 1 x 1" Nylon spacer 3/16" diameter 2 x Universal "L" brackets 1 x Universal straight bracket 1 x Torsion spring, 90 degrees 1 x Brass rod with ring terminal connector Miscellaneous 1 x 3M Safety glasses 1 x Super Lube white grease 1 x Combination wrench - not pictured 1 x Servo horn connector, brass 1 x Parallax Standard Servo Foam tape, 10" strip - not pictured Dimensions Size 7.8 x 8.4 x 4.3 cm Multimedia

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Parallax
Type	Parallax
MPN	28203
UPC	Does not apply
