Grove Lora Radio 868mhz

US $21.89

Swanton, Vermont, United States
Jul 24th

Open on mobile:
QR code

Description Grove LoRa Radio 868MHz Features a RFM95 transceiver Provides ultra-long range spread spectrum communication Is ATmega168 The Grove LoRa Radio 868MHz is RFM95, which is a transceiver features the LoRa long range modem that provides ultra-long range spread spectrum communication and high interference immunity whilst mini-missing current consumption. The heart of Grove - LoRa Radio 868MHz is ATmega168, a widely used chip with very high-performance and low power consumption, especially suitable for this grove module. A simple wire antenna to receive signal has already been integrated, if the signal is too weak to receive, don’t worry, the MHF connector next to the antenna is for adding a second antenna which has MHF interface to gain more signal. This is the 868 MHz version, which can be used for 868 MHz communication. Specifications Using RFM95 module based on SX1276 LoRa Inputting voltage: 5 V / 3.3 V 28 mA (Avg) +20 dBm continuous transmit 8.4 mA (Avg) standby mode 20 mA (Avg) receive mode, BW-500 kHz Working Temperature: -20 – 70 Communication Interface: UART Simple wire antenna or MHF Connector for external high gain antenna Working Frequency: 868 MHz +20 dBm - 100 mW Power Output Capability Weight: 11 g What's Included 1 x Grove LoRa Radio 868MHz 1 x Grove - cable Dimensions Size 135 x 85 x 10 mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	SeeedStudio
Type	SeeedStudio
MPN	113060006
UPC	Does not apply
