Gsm/gprs Module - Sm5100b

US $89.95

Rockaway, New Jersey, United States
Jan 29th

Open on mobile:
QR code

CHECK OUT MY OTHER ITEMS! Be sure to add me to your favorites list! GSM/GPRS Module - SM5100B Description: The SM5100B is a miniature, quad-band GSM 850/EGSM 900/DCS 1800/PCS 1900 module, which can be integrated into a great number of wireless projects. You can use this module to accomplish almost anything a normal cell phone can - SMS text messages, GSM/GPRS, TCP/IP, and more! This module features two UARTS, an SPI interface, and two 10-bit ADCs. It also supports Li-ion battery charging, a 4x6 keypad, and an LCD interface. Inputs/outputs are available for a speaker and microphone. An antenna does come attached to the module. Power supplied to the module should be regulated between 3.3-4.2VDC (3.6V nominal). You can connect it up to a mating 60-pin, surface mount connector, or you can pair this module with our SM5100B evaluation board. There is no SIM socket on the actual cell module, you might want to consider using our SIM card breakout board. Features: Temperature range: -10-55°C (operating), -40-85°C (storage) Connection: 60 pins, mating connector sold separately Power Supply: VBAT: 3.3V to 4.2V range, 3.6V typical Power Consumption: Off mode: <100uA Sleep mode: <2.0mA Idle mode: <7.0mA (average) Communication mode: 350 mA (average,GSM) Communication mode: 2A (Typical peak during TX slot,GSM) Frequency Bands: EGSM900 +GSM850+ DCS1800+PCS1900 Transmit Power: Class 4 (2W) for EGSM900/GSM850 Class 1 (1W) for DCS1800/PCS1900 Supported SIM card: 3V/1.8V SIM card. (auto recognize) 4x6 keyboard interface available UART0 interface with flow control, up to 460kbps UART1 interface without flow control, two-wire interface, up to 460kbps LCD interface available, over SPI Dimensions: 35.0 x 39.0 x 2.9mm Weight: <9g Users Manual Hardware Specification Reference Schematics SMS Application Notes GPRS Application Notes AT Command Set Arduino Tutorial SAVE 10% for 10 units or 20% for 100 units. Email us for prices We provide additional information as: Hablamos Espanol, Parlais Francais, Parle Italiano,Falam Portugues. Nous parlons votre langue , nous envoyer un courriel avec des questions. Hablamos tu idioma , envianos un mail con cualquier consulta. Falamos a sua lingua , um e-mail com todas suas perguntas. Parliamo la vostra lingua , inviare un'e-mail con tutte le domande. International Shoppers, contact us for shipment and quantity prices, we ship worldwide and we have excellent discounts for extra quantities Compradores Internacionales contactenos por precios de envios. Disponemos de excelentes descuentos por cantidades. Atencion en Espanol e Ingles On Nov-21-14 at 10:57:37 PST, seller added the following information: Every buyer gets a MyStoreRewards invitation for cash back
