Home page About Us Feedback See our other products Add to Favourite Contact us Shop categories Baby Automotive Electronics Home Improvement Kitchen & Dining Home & Kitchen Musical Instruments Office Products Toys & Games Shop pages Home page See Our Other Products Add to Favourite About the seller GW Instek GDS-1052-U 5.7" LCD Color Display Digital Storage Oscilloscope with USB Port, 50MHz Bandwidth, 2-Channel, 7ns Rise Time Product Specification Two-channel, portable digital oscilloscope for electronics applications such as product design, assembly lines, repair and servicing, and electrical engineering education Maximum real-time sample rate of 250MS/s and record length of 4 kpts per channel for acquiring detailed waveforms Auto-set function automatically selects the optimum settings for displaying waveforms Add, subtract, and FFT math functions and 19 measurement parameters for analyzing waveforms 5.7" color TFT-LCD for simultaneously viewing up to two live and two stored waveforms Features The Instek GDS-1000-U series is a two-channel, portable digital oscilloscope with a maximum real-time sample rate of 250MS/s, a record length of 4 kpts, auto-set function, advanced triggering, two basic math functions and FFT, 19 measurement parameters, an internal memory for data storage, data logging, and USB connectivity for electronics applications such as such as product design, assembly lines, repair and servicing, and electrical engineering, among others. The sample rate and record length enable long capture times for displaying detailed waveforms. An auto-set function automatically configures the optimum settings for displaying waveforms by selecting the horizontal and vertical scales, positioning the waveform horizontally and vertically, and selecting and activating the trigger source channel. In addition to an edge trigger, the unit has pulse width and video triggers for isolating a specific signal. Two basic math functions?add and subtract?plus FFT (fast fourier transform) and 19 measurement parameters such as average, frequency, and peak-to-peak allow an in-depth analysis of waveforms. A go/no go test function promptly indicates when a signal falls outside user-defined settings, and a zoom function magnifies details of waveforms. Up to 15 waveforms or 15 setups can be stored in the internal memory of the oscilloscope. A data logging function tracks data at user-defined timed intervals for up to 100 hours, logging the data on a USB flash drive (sold separately). Additional specifications include a rise time of 7ns for the 50MHz model, 5ns for the 70MHz model, and 3.5ns for the 100MHz model, and various triggering features. The oscilloscope has a 5.7" color TFT (thin film transistor) LCD with a resolution of 320 x 234 pixels and can show simultaneously show up to two live and two stored waveforms. The oscilloscope has a USB host port for connecting a flash drive (sold separately) to store data and a USB device port for connecting to a PC for storing data and remote operation. The unit meets EN (European Standard) 61010-031 safety standard, and is rated for CAT (category) II installations to 300V, which covers energy-consuming equipment connected to a fixed installation, including household, office, and laboratory appliances. It has CE (European Conformity) marking. It comes with two passive voltage probes, a power cord for 100 to 240VAC, 50/60Hz, and a user manual. Specifications Display 5.7" color TFT-LCD Bandwidths available 50, 70, 100MHz Channels Two Maximum real-time sample rate 250MS/s Record length 4 kpts Installation rating CAT II, 300V Standards met EN 61010-1-031; CE marking Power source Power cord for 100 to 240VAC, 50/60Hz Dimensions (H x W x D) 142 x 310 x 140 mm Weight 2.5 kg H is height, the vertical distance from lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. Oscilloscopes are electrical testing devices used to verify the functionality of equipment that generates an electrical signal. Oscilloscopes measure the voltage of an electrical signal over time, and display the measurement as a waveform in a visual graph. The waveform shows the sweeps (or refresh) of voltage on a vertical (Y) axis, and the time on a horizontal (X) axis. Details of a waveform demonstrate the signal over time. Most oscilloscopes have two or four channels for inputting a signal. Some digital oscilloscopes offer more than four channels, allowing channels to be dedicated to specific signals and applications. Bandwidth is the maximum frequency of a signal that an oscilloscope can capture. A constant image will display if a signal is shown at a high frequency. Oscilloscopes may be analog, digital, or mixed signal. An analog oscilloscope directly displays an input signal as a continuous waveform, typically in a luminous phosphor on a cathode ray tube (CRT). A digital oscilloscope converts the input signal into a digital format and reassembles the waveform for display, typically on an LCD. A mixed signal oscilloscope (MSO) displays both analog and digital formats. Some oscilloscopes can display more than one channel and type of measurement simultaneously. Some oscilloscopes can capture waveform signals to memory, and recall them. They may provide real-time intensity grading, and may have the ability to adjust frequency of display. Oscilloscopes can be powered with batteries or electricity, or may have a built-in generator. They are commonly used for testing, measuring, and inspecting in science, engineering, telecommunications, automotive, and electronics applications. GW Instek manufactures test and measurement equipment such as oscilloscopes, spectrum analyzers, signal testers, and video surveillance systems. The company, founded in 1975 and headquartered in Taipei, Taiwan, meets International Organization for Standardization (ISO) standards 9002 and 14001. What's in the Box? Instek GDS-1000-U series digital oscilloscope (2) passive voltage probes Power cord User manual Additional Information Manufacturer: GW Instek Shipping Weight: 780 Product Dimensions: Width: 10.40 Length: 15.70 Height: 8.70 Delivery Information Refunds & Returns About Us Our Guarantee Contact Us All our stock is at our US warehouse.Your item will be shipped by either DHL or UPS depending on the size/weight of the package and delivery location. We aim to ship orders within 24hours of processing your payment. Shipping is free. 30 day return or exchange policy for all our products. Only factory defects are accepted as the reason for product return. Returned item(s) must be returned with package completely intact, and all accessory(s) inside the package must be original condition.We do not pay for the postage costs for returned defective items.Items returned must be received within 30 days from purchase. No refund or replacement is issued after 30 day time period after purchase. Please allow up to 7 working days to process your returned item(s) after we receive it.We are extremely fair, and in the rare event of something unusual happening, we will gladly work with you to find a solution. We sell on eBay since 2007. We are based in the US and ship from our own warehouses. Our products are 100% authentic and all brand new. We work with the biggest suppliers in the UK to bring you the best quality items!We guarantee to provide the best service. Customer satisfaction guaranteed!We offer a 100% Satisfaction Guarantee on all sales. If you are not happy with your purchase for any reason, please contact us within seven days of receipt of your item, or email us to share your concerns. We are extremely fair and will happily work with you to find a solution to any problem.We aim to maintain 100% feedback, and we want every single one of our customers to be a happy one. So in the rare case something does go wrong, before leaving a negative feedback, contact us so we can help make things right! In the rare event that you have an issue with your product or our service please contact us by email to share your concerns, we will respond within 24 hours to help to rectify the problem.
