H+p Telemodul 40 Ct Stirrer Control Unit

US $1200

Natick, Massachusetts, United States
May 29th

Open on mobile:
QR code

This listing is for an H+P TELEMODUL 40 CT Stirrer Control Unit What you will get: H+P TELEMODUL 40 CT Stirrer Control Unit Power Cord Other information: TELEMODUL 40 CT Powerful control unit with 40 W rated power (stirrer) and electronic temperature control for electric heaters at up to +200° C; suitable for VARIOMAG reaction blocks and (as of the summer of 2000) for stirring block thermostats and MULTITHERM stirring/heating plates. Microprocessor-controlled, user-friendly, menu-driven settings Single-hand operation - just turn and press the adjustment wheel Large graphic display - all settings visible at a glance Three individually programmable program keys for rapid startup - the last settings in effect are stored automatically RS 232 interface for PC control User interface in four languages (English, French, German, Spanish) Stirrer control: Intermittent operation with freely adjustable stirring and pause times and rotation sense inversion (5 s - 1 h) Start / Stop key for recentring, safe starting, and rapid stopping of the stirring bar Vertical mixing (shake mode) Adjustable speed range 100-2000 rpm in 5 rpm increments Stirring bar rotates evenly, even at low speeds Three different settings (1x, 2x, 4x) for assured startup acceleration of the stirring bar, even in highly viscous liquids Ten different power settings (10%25 to 100%25) with more power for larger quantities and more viscous liquids and reduced power for long-term operation without heat generation Heater control: Electrical heating unit up to +200° C in 1 K increments Additional independent temperature control loop, mechanically adjustable at the back of the unit (safety loop for unattended operation) Temperature control by optional liquid temperature sensor (please inquire) Control hysteresis between 0.5 K and 10 K in 0.5 K increments Timer for block operation up to 8 h in one-second increments ACCESSORIES For TELEMODUL 40CT Pt-100 temperature sensor for liqud temperature control Adapter for reaction block (separate connectors for control and heating) Technical Specifications: Type: TELEMODUL 40 CT 15pin plugin two separate connectors Stirring power (relativ to rated power) (%25) (8 power settings) 30 - 100 Rated power (VA) 40 40 Heating power (W) -1000 -2000 (-1000 bei 115V) Speed (1/min) 100 bis 2000 Constancy of speed (%25) +/- 3 Set temperature range 10° C higher than ambient temp. up to +200° C Dimensions WxDxH (mm) 255 x 180 x 90 Weight (kg) 2,0 Ambient temperature at 80%25 humidity (°C) 0 bis +40° Operation voltage 115 VAC / 60 Hz 100-240 VAC / 50-60 Hz Output voltage (Veff.) 2 x 36 / 100-240 VAC Priotection acc. to DIN 40050 IP 20, Protection class I Order No.: (115V) 90688 90689 This ships free in the USA. If you receive your item and it is not to your 100 Percent Satisfaction, please contact us before leaving feedback. I strive to make sure every transaction is a positive one! I wanted to reach out and let you know that eBay is changing the way Sellers are rated. I am not overjoyed with what's happening, but I have to roll with it. IF you have a problem with my item, I would like you to use the "Contact Seller" link in the listing, or call me. Please don't open a case. Cases count against me even if they are resolved. I stand behind my items and will work out any problems that you may have with an item. So please contact me if you have a problem with an item I have sold you and don't use the eBay Case as a means of communication. International Buyers, Please Note: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. These charges are normally collected by the delivering freight (shipping) company or when you pick the item up do not confuse them for additional shipping charges. We do not mark merchandise values below value or mark items as "gifts". US and International government regulations prohibit such behavior. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
