Haas Automation Inc. 08' Mill And Lathe "service" Manual/mechanical Components

US $100.00

  • Moorpark, California, United States
  • Jan 30th
Open on mobile:
QR code
Up for BIN type auction is a new reproduction of the 460 page HAAS Automation Inc. 08' Mill and Lathe "SERVICE" Manual/Mechanical Components. Unavailable for order from the factory. Get the same manual the (EXPENSIVE) HAAS Service Techs use. This manual covers the following: Mill and Lathe- General Machine Trouble Shooting TRP Assembly Spindle Troubleshooting Automatic Tool Changer (ATC) Side Mount Tool Changer (SMTC) Turret Crash Recovery Procedure Ball Screw Removal and Installation EC-300 MDC Pallet Changer EC-400 Pallet Change Automatic Pallet Changer (APC) (vertical machines) Setting the grid offset 4th Axis Repair (Horizontal) H-Frame Pallet Alignment EC-630 Harmonic Drive (Horizontal) Lubrication System Parts Catcher (Lathe) Lathe Tool Probe Horizontal Mill Assembly Drawings and Parts List Vertical Mill Assembly Drawings and Parts List Lathe Assembly Drawings and Parts List *see pictures of the contents pages for full listing of features You will receive your reproduced manual bound in a new three ring binder. This is a must have for any shop utilizing HAAS Machine Tools.
