Haas Tr160 Series Trunnion Rotary Table

US $2700

  • Reidsville, North Carolina, United States
  • Jun 22nd
Open on mobile:
QR code
This Haas TR160 Series Trunnion Table was purchased in 2010 and was gently used for 4 years prior to the purchase of a larger table.  Item was in great working condition upon removal of application.  This item has been stored in our warehouse.  Listing includes everything shown in the pictures. Shipping is Listed as Local pick up in Reidsville NC.   Please ask if you would like pricing on freight to your location. Payment should be received within 7 days from purchase date.   Technical Data:     Rotary B axis Tilt A axis SPINDLE     Torque 100ft-lb  136Nm 150 ft-lb  203Nm Runout Max. 0.0005” 0.013 mm N/A Platter Pilot ID 1.500”X 4.63” dp N/A Backlash 30 arc-sec 30 arc-sec Speeds 0.001 to 80degree/sec 0.001 to 80degree/sec Brake Torque@100psi 100 ft-lb  136 Nm 200 ft-lb 271 Nm INDEXING     Accuracy +- 15 arc-sec +- 15 arc-sec Repeatability 10 arc-sec 10 arc-sec Resolution 0.001 degree 0.001 degree Max Rotation/Step 999.999 degree 999.999 degree MOTOR     Gear Ratio 63:1 63:1 Timing Belt 2:1 2:1 PLATTER   Part Swing (max)2 17.5”  445 mm Capacity 80 lb  36 kg Platter Diameter 6.3”  160 mm OPERATING SPECIFICATIONS   Duty Cycle full/low speed 50% / 100% Operating Temp. (max ambient) 100 Degree F   38 Degree C Power Required (VAC) 1 axis control 115 +- 10% @ 15A Power Required (VAC) 2 axis control 235 +- 10% @ 20A Max Air Pressure 120 psi   8.3 bar WEIGHT   Table 425 lb  193 kg Brushless Control 23.1 lb (2-axis)  14.2 lb(1-axis) 10.5 kg(2-axis)  5.4 kg (1-axis) -Simple Bolt on Mounting -5 axis solution to your 3 axis mill -Machine multiple sides in one setup -High accuracy and repeatability -Brushless Servomotors -Made in USA
