Handheld Isolated Oscilloscope Scopemeter 60mhz 1gs/s 2m Memory & Dmm Usb 1062s

US $644.99

Shenzhen, China
Jan 29th

Open on mobile:
QR code

DSO1062S Features: • Isolated level:1000V CATII,600V CATIII. • High Bandwidth 60MHz-200MHz Oscilloscope,1GSa/s sample rate, and 6000 Counts DMM with analog bargraph , and data recorder. • 1M Memory Depth. • High Refresh Rate (2500 frames) • Large 5.6 inch TFT Color LCD Display,High Resolution(640*480), Dual-Window Design --More clear, More Detailed • One-touch automatic setup optimizes the position, range, timebase, and triggering to assure a stable display of virtually any waveform • Easy-to-use pop-up menu with built-in multi-language help system • 23 Automatic Measurements • Waveform Math: Add, Subtract, Multiply, and Divide • Store and recall over • Automatic cursor tracking measurements • XY Mode • Built-in FFT function converts a time-domain signal into its frequency components to measure harmonic content and distortion in systems • Waveform Recorder to capture/replay input waveforms from CH1 and CH2 with a maximum record length of 1000 frames • Pass-Fail function compares a stored waveform to an unknown input • Average Mode for smoothing waveforms • Square Wave Output (2V, 1kHz) for probe adjustment • USB Host/Device 2.0 full-speed interface ,support removeable disk, LAN Optional ,Easy to control by PC or long-distance. • Dimensions (mm):240(L)x165(W)x50(H), be carried easily. V Specification Model DSO1202S DSO1122S DSO1062S Oscilloscope Mode Vertical Bandwidth 200MHz 120MHz 60MHz Real-time Sample Rate 1GSa/s Equivalent Sample Rate 25GSa/s Record Length (Sample Points) Single-channel: Maximum 2M; Dual-channel: Maximum 1M SEC/DIV Range 2nS/div-2000S/div (in a 2, 4, 8 sequence) A/D Converter 8-bit resolution VOLTS/DIV Range 2mV/div~5V/div at input BNC Position Range ±50V(5V/div),±40V(2V/div~500mV/div),±2V(200mV/div~50mV/div)±400mV(20mV/div~2mV/div) Rise Time at BNC

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	DSO1062S
Channels	2
MPN	DSO1062S
Sample Rate	1GSa/s - 1.9GSa/s
Type	Digital
Number of Channels	2
Bandwidth	60MHz - 99MHz
Country of Manufacture	China
