Hantek Dso8152e 6 In1 150mhz Oscilloscope Dmm Spectrum Analyzer Wave Generator

US $690.00

HONG KONG, Hong Kong
Jun 9th

Open on mobile:
QR code

Hantek DSO8152E 6 in1 150MHz Oscilloscope DMM Spectrum Analyzer Wave Generator Hantek DSO8152E 6 in1 150MHz DSO8000E Series This item MPN#: DSO8152E-150Mhz Six in one: Oscilloscope/Recorder/DMM/ Spectrum Analyzer/Frequency Counter/Arbitrary Waveform generator. IP-51 rated for dust, drip and shake proof to withstand harsh environments. Large fuse confirms to European Safety Standard. Battery indicator with easy-changed connect points. Selectable 18650 battery box for matching 18650 battery by yourself. Anti-theft lock hole, tripod fixed hole, hang rope, FLASH light that can be used in darkness. Replaceable BNC safety joints, and additional one set of joints. High bandwidth 70MHz-200MHz Oscilloscope, 1GSa/s sample rate, 2M Memory depth. 25Mz Arb. Waveform Generator, 200 Mesa/s DDS, 12 bit vertical resolution, easy for simulating transducer 6000 Counts DMM, AC/DC voltage, AC/DC current, resistance, break, capacitance, and diode function. FFT spectral analysis; Waveform Math: add, subtract, multiply and divide; X-Y mode; more than 20 automatic measurements; PASS/FAIL Check function, apply to engineering application. Abundant trigger function, double timebase sampling, easy to observe two waveforms in different frequency. Record and replay of more than 1000 waveforms. Large 5.6 inch TFT Color LCD Display; High Resolution(640*480) USB Host/Device 2.0 full-speed interface; support removable disk; WIFI/LAN Option, easy to control by PC or long-distance. Waveform data can be output in WORD,EXCEL, BMP, JPG as time and voltage. Function Picture Model DSO8072E DSO8102E DSO8152E DSO8202E Acquisition Sample Modes Real-Time Sample Acquisition Modes Normal Normal data only Peak Detect High-frequency and randon glith capture Average Wavefom Average, selectable 4,8,16,32,64,128 Inputs Inputs Coupling AC, DC, GND Inputs Impendance 1MΩ±2% ‖20pF±3pF Probe Attenuation 1X, 10X Supported Probe Attenuation Factor 1X, 10X, 100X, 1000X Maximum Input Voltage CAT I and CAT II: 300VRMS (10×), Installation Category; CAT III: 150VRMS (1×) Horizontal System Sample Rate Range 1GS/s Waveform Interpolation (sin x)/x Record Length 2M SEC/DIV Range 4ns/div~2000s/div, in a 2, 4, 8 sequence 2ns/div~2000s/div, in a 2, 4, 8 sequence Sample Rate and Delay Time Accuracy ±50ppm over any ≥1ms time interval Scanning Speed Range 4ns/div to 8ns/div; (-8div x s/div) to 40ms; 20ns/div to 80μs/div;(-8div×s/div) to 40ms; 200μs/div to 40s/div;(-8div×s/div) to 400s; 2ns/div to10ns/div;(-4div×s/div) to 20ms; Delta Time Measurement Accuracy (Full Bandwidth) Single-shot, Normal mode:± (1 sample interval +100ppm × reading + 0.6ns); >16 averages:± (1 sample interval + 100ppm × reading + 0.4ns); Sample interval = s/div ÷ 200 Vertical System Vertical Resolution 8-bit resolution, all channel sampled simultaneously Volts Range 2mV/div to 100V/div at input BNC Bandwidth 70MHz 100MHz 150MHz 200MHz Rise Time at BNC( typical) 5ns 3.5ns 2.3ns 1.8ns Analog Bandwidth in Normal and Average modes at BNC or with probe, DC Coupled ±400V(100V/div-20V/div); ±50V(10V/div-5V/div); ±40V(2V/div-500mV/div); ±2V(200mV/div-50mV/div); ±400mV(20mV/div-2mV/div); Math +, -, *, /, FFT FFT Windows: Hanning, Flatop, Rectamgular, Bartlett, Blackman; 1024 sample point Bandwidth Limit 20MHz Low Frequency Response (-3db) ≤10Hz at BNC DC Gain Accuracy ±3% for Normal or Average acquisition mode, 100V/div to 10mV/div. ±4% for Normal or Average acquisition mode, 5mV/div to 2mV/div. DC Measurement Accuracy, Average Acquisition Mode Measurement Type: Average of ≥16 waveforms with vertical position at zero Accuracy: ± (3% × reading + 0.1div + 1mV) when 10mV/div or greater is selected. Measurement Type: Average of ≥16 waveforms with vertical position not at zero Accuracy: ± [3% × (reading + vertical position) + 1% of vertical position + 0.2div]. Volts Measurement Repeatability, Average Acquisition Mode Delta volts between any two averages of ≥16 waveforms acquired under same setup and ambient conditions Trigger System Trigger Types Edge, Video, Pulse, Slope, Over time, Alternative Trigger Source CH1, CH2, AC Line Trigger Modes Auto, Normal, Single Coupling Type DC, AC, HF Reject, LF Reject, Noise Reject Trigger Sensitivity (Edge Trigger Type) DC(CH1,CH2): 1div from DC to 10MHz; 1.5div from 10MHz to 100MHz; 2div from 100MHz to Full; AC: Attenuates signals below 10Hz ; HF Reject: Attenuates signals above 80kHz; LF Reject: Same as the DC-coupled limits for frequencies above 150kHz; attenuates signals below 150kHz. Trigger Level Range CH1/CH2: ±8 divisions from center of screen; Trigger Level Accuracy( typical)Accuracy is for signals having rise and fall times ≥20ns CH1/CH2: 0.2div × volts/div within ±4 divisions from center of screen; Set Level to 50%(typical) Operates with input signals ≥50Hz Video Trigger Video Trigger Type CH1, CH2: Peak-to-peak amplitude of 2 divisions; Signal Formats and Field Rates Supports NTSC, PAL and SECAM broadcast systems for any field or any line Holdoff Range 100ns ~ 10s Pulse Width Trigger Pulse Width Trigger Mode Trigger when (< , >, = , or ≠); Positive pulse or Negative pulse Pulse Width Trigger Point Equal: The oscilloscope triggers when the trailing edge of the pulse crosses the trigger level. Not Equal: If the pulse is narrower than the specified width, the trigger point is the trailing edge. Otherwise, the oscilloscope triggers when a pulse continues longer than the time specified as the Pulse Width. Less than: The trigger point is the trailing edge. Greater than (also called overtime trigger): The oscilloscope triggers when a pulse continues longer than the time specified as the Pulse Width Pulse Width Range 20ns ~ 10s Slope Trigger Slope Trigger Mode Trigger when (< , > , = , or ≠ ); Positive slope or Negative slope Slope Trigger Point Equal: The oscilloscope triggers when the waveform slope is equal to the set slope. Not Equal: The oscilloscope triggers when the waveform slope is not equal to the set slope. Less than: The oscilloscope triggers when the waveform slope is less than the set slope. Greater than: The oscilloscope triggers when the waveform slope is greater than the set slope. Time Range 20ns ~ 10s Overtime Trigger Over Time Modee Rising edge or Falling edge Time Range 20ns ~ 10s Alternative Trigger Trigger on CH1 Internal Trigger: Edge, Pulse Width, Video, Slope Trigger on CH2 Internal Trigger: Edge, Pulse Width, Video, Slope Trigger Frequency Counter Readout Resolution 6 digits Accuracy (typical) ±30ppm (including all frequency reference errors and ±1 count errors) Frequency Range AC coupled, from 4Hz minimum to rated bandwidth Signal Source Pulse Width or Edge Trigger modes: all available trigger sources The Frequency Counter measures trigger source at all times, including when the oscilloscope acquisition pauses due to changes in the run status, or acquisition of a single shot event has completed. Pulse Width Trigger mode: The oscilloscope counts pulses of significant magnitude inside the 1s measurement window that qualify as triggerable events, such as narrow pulses in a PWM pulse train if set to < mode and the width is set to a relatively small time. Edge Trigger mode: The oscilloscope counts all edges of sufficient magnitude and correct polarity. Video Trigger mode: The Frequency Counter does not work. Measure Cursor Measurement Manual: Voltage difference between cursors: △V Time difference between cursors: △T Reciprocal of △T in Hertz (1/ΔT); Tracing: The valtage and time at a waveform point; Auto Measuerment Frequency, Period, Mean, Pk-Pk, Cycli RMS, Minimum, Maximum, Rise time, Fall Time, +Pulse Width, -Pulse Width, Delay1-2Rise, Delay1-2Fall, +Duty, -Duty, Vbase, Vtop, Vmid, Vamp, Overshoot, Preshoot, Preiod Mean, Preiod RMS, Waveform Generator Mode Frenquency Range 1Hz(DC)~25MHz DAC Clock 2K~200MHz adjustable Memory Depth 4KSa Vertical Resolution 12 Bits Stability <30ppm Amplitude ±3.5V Max. Output Impedance 50 Ω Output Current 50mA Ipeak=50mA System Bandwidth 25M Harmonic Wave Distortion -50dBc(1KHz), -40dBc(10KHz) General Specifications Display Resolution 640 horizontal by 480 vertical pixels Display Contrast Adjustable (16 gears) with the progress bar Probe Compensator Output Output Voltage( typical) About 2Vpp into ≥1MΩ load Frequency(typical) 1kHz Power Supply Supply Voltage AC Input:100-240VACRMS,0.6A MAX,50Hz~60Hz; DC Output:9V,2A Power Consumption <30W Environmental Temperature Operating: 32℉ to 122℉ (0℃ to 50℃); Nonoperating: -40℉ to 159.8℉ (-40℃ to +71℃) Cooling Method Convection Humidity +104℉ or below (+40℃ or below): ≤90% relative humidity; 106℉ to 122℉ (+41℃ to 50℃): ≤60% relative humidity Altitude Operating: Below 3,000m (10,000 feet); Nonoperaring: Below 15,000m(50,000 feet) Mechanical Size 260mmmm; 220mm; 75mm Weight 2.5KG(without Packing) DMM Mode Max. Resolution 6000 Counts DMM Testing Modes Voltage, Current, Resistance, Capacitance, Diode & Continuity Max. Input Voltage AC:600V, DC: 800V Max. Input Current AC: 10A, DC:10A Input Impedance 10MΩ DMM TrendPlot 1.2M Point Range Resolution Accuracy Resolution DC Voltage 60.00mV ±1%±3 digit 10uV 600.0mV 100uV 6.000V 1mV 60.00V 10mV 600.0V 100mV 800V 1V AC Voltage 60.00mV ±1%±3 digit 10uV 600.0mV 100uV 6.000V 1mV 60.00V 10mV 600.0V 100mV DC Current 60.00mA ±1%±5 digit 10uA 600.0mA ±1.5%±5 digit 100uA 6.000A 1mA 10.00A 10mA AC Current 60.00mA ±1%±5 digit 10uA 600.0mA ±1.5%±5 digit 100uA 6.000A 1mA 10.00A 10mA Resistance 600Ω ±1%±3 digit 0.1Ω 6.000KΩ 1Ω 60.00KΩ 10Ω 600.0KΩ 1KΩ 6.000MΩ 10KΩ 60.00MΩ ±1%±5 digit 100KΩ Capacitance 40.00nF ±2%±5 digit 10pF 400.0nF 100pF 4.000uF 1nF 40.00uF 10nF 400.0uF 100nF Attention: the smallest capacitance value that can be measured in 5nF Diode 0V~2.0V ON-OFF test <10Ω Optional Accessories: Payment We accept PayPal only. But we only Accept your Ebay Address,Please Make sure it's 100% right. Payment must be received in 5 business days of auction closing. Please leave note for your special request (e.g. Voltage,Colors or Size) in PayPal when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. Delivery details We only accept your Ebay Address,Please Make sure it's 100% right. The items you ordered will be shipped out in 1 business day by Hong Kong Air Mail when your payment is clear. The arrival time is 5-20 business days to United States usually. We maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important to us. We request that you contact us immediately BEFORE you give us neutral or negative feedback, so that we can satisfactorily address your concerns. We ensure dispatch the item within 1-2 business days. However, you bought the item from opposite side of the earth, so it needs a little longer time to deliver. Please place order only if you agree with the shipping time and all the terms below. Customs duty is obligation and liability of a citizen in your country, so buyer should be responsible for any tax and custom duty incurred. Generally, the delay or failure delivery is sometimes caused by the policy of different customs. Therefore, please double check your local customs policy carefully before purchase. Or, we will NOT be responsible for any failure delivery related destination customs issue. Terms of sales All package need to wait 30 days,Please take care it.Less than 30 days,we can't take a refund. If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. If is item is defective in 12 months, you can return it to us. We will send you a new replacement after receiving the defective item. About us PLC-Expert Contact us If you have any questions, please feel free to email our service specialists 24 Hours a Day, 7 Days a Week, and we will reply you ASAP. If no response within 24 Hours, please check the spam of mail box or kindly re-send it to us. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative or neutral feedback without any contact. If you haven’t received item in 30 days, please contact us and we will arrange refund. On Jul-30-15 at 13:16:13 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Hantek
Bandwidth	70~200
Model	DSO8000E
Channels	2
MPN	DSO8000E
Sample Rate	1G/S
Type	Digitial
UPC	Does not apply
