Hantek Handheld Dso8060 60mhz 5in1 Oscilloscope Waveform Dmm Spectrum Frequency

US $2900

shenzhen, China
Jan 29th

Open on mobile:
QR code

[zipedit] Our-Store Home Page About Us Contact Us Add to Favourate Payment Shipping Return Categories Payment Why Us Subscribe NewsLetter Add our store in to your favourites and recieve our exclusive emails about new items and special promotions Subscribe Product Overview Description Hantek Handheld DSO8060 60MHz 5in1 Oscilloscope Waveform DMM Spectrum Frequency (DC-OT11174) The item will be sent via TNT or DHL. SC Five-in-one mobile laboratories: oscilloscope/arbitrary source/frequency spectrum analysis/counter/multimeter Wave Pictures: MATH, REF 6000 COUNTS Digital Multimeter The cursor function ALT MAG, easy to search for signal X-Y mode FFT Provides spectrum analysis function Test signal more than 100MHz by ETS mode Document management, convenient file storage and management Built-in help system 22 kinds of waveform measurements ALT trigger mode, dual time base, easy to observe two signals of different frequency Characteristic(Handheld Oscilloscope/Multimeter) DSO8060 Five-in-one Handheld Oscilloscope.Oscilloscope/DMM/ Spectrum Analyzer/Frequency Counter/Arbtrary Waveform generator. High Bandwidth 60MHz Oscilloscope ,and 6000 COUNTS high precision DMM.Seperated GND Reference.Hardware Frequency Counter. Arbitrary Waveform Generator: 25Mz arbitrary waveform output, (sine wave can deliver up to 75 Mz) 200 MSa / s DDS, 12 bits of vertical resolution. FFT , + , - , * , / ,X-Y, 22 kinds of auto measurements, PASS/FAIL Check ,easy to use on production line. High refresh rate,High Real-time Sample Rate 150MS/s-2GS/s, 50GS/s Equivalent-time Sample Rate. Multiform Trigger mode ,2 separate Time Base in ALT Trigger mode ,easy to see 2 signal with different frequency. 1000 waveforms save and record. Excellent Industrial Design .Direct key for Each Channel ,Time base ,Trigger and DMM,easy to operate. Large 5.7 inch TFT Color LCD Display ,Led backlight,Display clearly. USB Host/Device 2.0 full-speed interface ,support removeable disk, RS-232/LAN Optional ,Easy to control by PC or long-distance. Battery Power Operation (Installed) Industrial Design. Save waveform in the following: jpg/bmp graphic file, MS excel/word file. Dimensions (mm):240(L)x165(W)x50(H), be carried easily. Labview\VB\VC Second Design instance. Hardware Specifications: Mode DSO8060 Oscilloscope Mode Vertical Channel 2 Bandwidth 60MHz Rise Time 5.8ns Input Impedance Resistance: 1M ; Capacitance: 15 pF Input Sensitivity 10mV/div to 5V/div Input Coupling AC, DC and GND Vertical Resolution 8 bits DC Gain Accuracy ±3% for Sample or Average acquisition mode Maximum Input 400V(DC+AC Peak) Horizontal Real-Time Sampling Rate 250MSa/s Equivalent Sampling Rate 50GSa/S Memory Depth 32k single channel, 16k double channels Time Base Range 5ns/div~1000s/div Time Base Precision ±50ppm Trigger Trigger Source CH1, CH2,EXT Trigger Mode Edge, Pulse Width, Alternative, Video Trigger Sensitivity (Edge Trigger Type) 1div from DC to 10MHz; 1.5div from 10MHz to 100MHz; 2div from 10MHz to Full; Trigger Level Accuracy, typical (Accuracy is for signals having rise and fall times >=20ns) ±(0.3divxV/div) (within ±4 divisions from center of screen) X-Y Mode X-Axis Input channel1 Y-Axis Input channel2 Phrase Shift Max.3 degree Auto Measure Voltage Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot Time Measurement Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle Delay Measurement Delay time from ch1 rising edge to ch2 rising edge Cursor Measure Cursors Measurement Manual, Track, Auto Measure Modes Data Deal Data Deal CH1+/- CH2, CH1xCH2, CH1/CH2, FFT, Invert Internal Storage Internal Storage 15 Waveforms and Setups Multimeter Mode Maximum Resolution 6,000 Counts Function Voltage, Current, Resistance, Capacitance, Diode & Continuity Maximum Input Voltage AC: 600V, DC: 800V Maximum Input Current AC: 10A, DC: 10A Input Impedance 10 M? Signal Source Mode Waveform Frequency DC~25MHz DAC Clock 2K~200MHz adjustable Frequency Resolution 0.1% Channel count 1CH waveform output Waveform Depth 4KSa Vertical Resolution 12 bit Frequency Stability <30ppm Waveform Range ±3.5V Max. Output Impedance 50 ? Output Current 50mA Ipeak=50mA System BW 25M Harmonic Distortion -50dBc(1KHz), -40dBc(10KHz) Measure Frequency Channel Frequency Range DC~60MHz Input Range 400mVpp~18Vpp Coupling Mode DC Frequency Measurement Accuracy ±Time Base Error ±1 Count Input Impedance > 100K? Digital in/out Bit 12 Bits Digital Generator Output and 6Bit Generator In Level LVCMOS Display TFT LCD Type 5.7 Inch with LED Backlight Display Display Resolution 240 (Vertical) x 320 (Horizontal) Dots Interface Standard USB Host / Device 2.0 Full Speed Supported Option RS232, LAN Power Source Power Adapter Input AC 100V ~ 240V, 50Hz ~ 60Hz;output 8.5VDC, 1500mA Battery Power(Standard) 6Hours (Li-ion Battery) Others Size 245 x 163 x 52 (mm) Separated GND Reference Oscilloscope and Multimeter Independence Software: Operating system:Windows 7, Windows NT, Windows 2000, Windows XP ,VISTA Package includes: 1 x DSO8060 oscilloscope 4 x oscilloscope probe 1 x USB cable 1 x CD (manual etc.) 1 x Power cord 1 x Hantek oscilloscope bag 1 x BNC line A 1 year warranty is offered for this product. Download the driver from the Following link:http://www.hantek.com/en/index.html We also provide other models of Hantek Oscilloscopes, the links are below: Model Custom Label Product Name MSO5202D DC-OT11238 Hantek MSO5202D 200MHz 2 Channel 1GSa/s Oscilloscope 16CH Analyzer FREE EXPRESS MSO5102D DC-OT11239 Hantek MSO5102D 100MHz 2 Channel 1GSa/s Oscilloscope 16CH Analyzer FREE EXPRESS DSO5202B DC-OT11241 Hantek DSO5202B 200MHz 2Channel 1GS/s Oscilloscope Scopemeter USB FREE EXPRESS DSO3064 Kit I DC-OT11242 Hantek DSO3064 Kit I PC-Base USB 60MHz 4CH 200MS/s Oscilloscope FREE EXPRESS DSO2090 DC-OT11243 Hantek DSO2090 100Msa/s 40MHz USB PC Scopemeter Oscilloscope FREE EXPRESS DSO2150 DC-OT11244 Hantek DSO2150 60MHz 150MSa/s 2 Channel PC USB Digital Oscilloscope FREE EXPRESS DSO5200A DC-OT11245 Hantek DSO5200A 200MHz 2 Channel 250MSa/s PC Based USB Oscilloscope FREE EXPRESS LA5034 DC-OT11246 Hantek LA5034 500MHz 34 Channel PC USB Logic Analyzer Oscilloscope FREE EXPRESS DDS3X25 DC-OT11247 Hantek DDS3X25 25Mhz 200Ms/s PC Function Waveform Oscilloscope FREE EXPRESS 1025G DC-OT11248 Hantek 1025G 25MHz 200MSa/s Waveform Generator DDS Oscilloscope FREE EXPRESS We also provide accessories of Hantek Oscilloscopes, the links are below: Model Custom Label Product Name HT301 DC-TE11233 http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=370931709928&ssPageName =STRK:MESE:IT HT201 DC-TE11234 http://k2b-bulk.ebay.com/ws/eBayISAPI.dll?MfcISAPICommand=ListingConsole¤tpage=LCActive&pageNumber=1&searchField=CustomLabel&searchValues=DC-TE11234&StoreCategory=-4&Status=All&Format=All&matchCriteria=and&srcFld_1 =Title&searchOpDd_1=CONTAINS&srcVal_ T3100 DC-TE11235 http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=221308377095&ssPageName=STRK:MESE:IT HT18A DC-TE11236 http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=221308378216&ssPageName=STRK:MESE:IT We also provide TEKTRONIX Oscilloscopes, links are below: Model Bandwidth Sample rate on each channel Link TBS1022 25MHz 500MS/s http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=371005639414&ssPageName=STRK:MESE:IT TBS1102 100MHz 1.0GS/s http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=371005648009&ssPageName=STRK:MESE:IT TDS2012C 100MHz 2.0GS/s http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=371005654564&ssPageName=STRK:MESE:IT TBS1042 40MHz 500MS/s http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=221372716828&ssPageName=STRK:MESE:IT Payment Shipping 100% Success Refund & Return Home Page About Us Contact Us Add to Favourate Payment Shipping Return Designed By XDiom Graphics

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Hantek
MPN	DSO8060
Model	DSO8060
Sample Rate	60MHz
