Hardinge Tool Setting Gage Bar

US $95.00

  • Vancouver, Washington, United States
  • Jun 9th
Open on mobile:
QR code
The tool setting gage is used to set cutting tools to the height of the spindle centerline quickly and accurately for longer tool life, easier cutting, better surface finishes and closer tolerances. The gage is hardened and ground to maintain accuracy and can be used for setting tools cutting on the front or rear of the workpiece. The gage has two ground surfaces "A" and "B". Surface "A" is for setting tools to cut on the front of the workpiece, surface "B" is for setting tools to cut on the rear of the workpiece. The top section swivels to cover and protect the ground gage surfaces. The gage can be set to the centerline of the spindle using the tool setting gage bar shown above which is held in a 1.000" or a 20mm round collet in the machine spindle. The gage can also be set using an indicator stand positioned on the top of the bed plate. A ground plug is held in a collet with the 1" travel indicator set to the top of the plug. The gage is then set to one-half the diameter of the ground plug.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Hardinge Adjustable Tool Setting Gage
