Harvard Apparatus 683 Small Rodent Ventillator

US $329.00

Redmond, Washington, United States
Jan 30th

Open on mobile:
QR code

This unit is used and in as-is condition. This is coming from a laboratory that is moving and downsizing. There are no returns. Full Description Back to Top • Model 683 for small animals from 250 g to 10 kg (22 lb) e.g. rats, hamsters, rabbits, cats, monkeys, small dogs, etc. • CE approved The Model 683 Small Animal Ventilator comes standard with two piston and cylinder assemblies. The smaller piston (which comes installed) allows tidal volumes to be set from 0.5 to 5.0 cc in 0.5 cc increments and the larger cylinder allows tidal volumes of 3.0 to 30 cc in 0.3 cc increments. Setting the cylinder stroke between gradations it is possible to achieve finer resolution in tidal volume settings. The 683 Ventilator features a numerical LED to display the respiratory rate which can be set from 18 to 150 strokes/minute. Volume and rate settings can be adjusted while the ventilator is running. The 683 Ventilator has four gas inlet and outlet ports: supply gas in, gas out (to animal), gas return (from animal) and ventilator exhaust. The ventilator exhaust can be attached to a column of water to achieve PEEP (positive end expiratory pressure) when long term animal ventilation is necessary. Overhaul kits are available for both the 683 and 687 ventilator models and are specific for the type of cylinder used. Overhaul kits include complete instructions and replacement parts. Specifications Back to Top Specifications 555282 555283 555284 550000 Number of Animals n/a n/a n/a 1 Species n/a n/a n/a Rats, Guinea Pigs, Rabbits Weight Range Minimum n/a n/a n/a 250 g Weight Range Maximum n/a n/a n/a 10 kg Tital Volume Minimum n/a n/a n/a 0.5 and 3 ml/stroke Tital Volume Maximum n/a n/a n/a 5 and 30 ml/stroke Stroke Volume Note n/a n/a n/a Adjustable from 0.2 to 30 ml/stroke while the ventilator is running Respiration Rate Minimum n/a n/a n/a 30 breaths/min Respiration Rate Maximum n/a n/a n/a 150 breaths/min Respiratory Rate Note n/a n/a n/a Adjustable from 30 to 150 strokes/min while the ventilator is running I:E Ratio n/a n/a n/a 1:1 Certifications n/a n/a n/a CE Port Size OD Metric n/a n/a n/a 5 mm Port Size English OD n/a n/a n/a 3/16 in Control Modes n/a n/a n/a Volume PEEP n/a n/a n/a Provided via attachment of water column Sigh Pressure n/a n/a n/a Not available Gas Supply n/a n/a n/a Room air or non-flammable mixed gas Sigh Frequency n/a n/a n/a none Display n/a n/a n/a Numerical LED displays rate Voltage Range n/a n/a n/a 115/230 VAC, 50/60 Hz Height Metric n/a n/a n/a 25 cm Height English n/a n/a n/a 10 in Width Metric n/a n/a n/a 20 cm Width English n/a n/a n/a 8 in Length Metric n/a n/a n/a 32.5 cm Length English n/a n/a n/a 13 in Net Weight Metric n/a n/a n/a 8 kg Net Weight English n/a n/a n/a 18 lb Model n/a n/a n/a 683 Thanks for Bidding!
