Hbl Insulgrip Twist-lock Plug Hbl2611 (hubbell)

US $180

Johnstown, Pennsylvania, United States
May 28th

Open on mobile:
QR code

•Product Item: Plug •Wiring Scheme: 2-Pole, 3-Wire Grounding •Amperage: 30A •Voltage: 125V AC •NEMA Configuration: L5-30P •Item Style: Insulgrip •Device Color: Black/White •Horsepower : 2 •Cord Dia: .360"-.930" (9-24) •Blade Holder Material: Natural White Nylon •Terminal Retainer Material: Clear polycarbonate •Housing Material : Black nylon •Cord Clamp Material: Natural (white) nylon •Blade Material: Brass •Terminal Clamp Material: .08" (2 )steel-nickel plated •Terminal Screw Material: #10-32 Brass (white finish on neutral screw when used) Multi-drive •Ground Screw Material: #10-32 Brass (green finish) Multi-drive •Cord Clamp Screw Material : Steel, zinc plated Multi-drive •Body Holding Screw Material: Steel, zinc plated Multi-drive •Ratings: Molded In or Stamped On •Catalog No: Permanently ink marked on product •Dielectric Voltage Withstand: 2,000V minimum •Current Interrupting Certified for current interrupting at full rated current •Temperature Rise: Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75. •Cord Accommodation: Round portable service cords of diameters commensurate with the device rating as defined in UL Standard 62, CSA C22.2 No. 49. •Terminal Accommodation: 30A #10 AWG •Terminal Identification: Terminals identified in accordance with UL 498 (X, Y, Z, White, Green) •Flammability: HB or better per UL 94 or CSA 22.2 No. 0.6 •Operating Temperatures: Maximum Continuous 75 C •Minimum -40 C (w/o impact) •Moisture Resistance: IP20 •Listings: FED SPEC UL/CSA •Weight in LBs: 0.25 •Product Dimensions: 4 x 2 x 2 inches. •Origin: China •The box is a little deformed by something crushing it, however it didn't harm the actual item for sale. Infact, this item is clean and in excellent condition. I do the best I can researching each individual item so that I can ensure you that I give you the best description of the item you plan on purchasing. As well as taking pictures to the best of my ability/phone allows me to do, that way you know what you see is what you get. The reason for the watermark is just for the purpose that no one can use my pictures as their own to mislead you. If you have any questions please feel free to contact me via message. Thank you for looking, & have a wonderful day!
