Hbl2360a 60v 2x75a Brushless Dc Motor Controller

US $819.50

Swanton, Vermont, United States
Aug 13th

Open on mobile:
QR code

Description 75A dual channel brushless DC motor controller Built-in dual 3-phase high-power drivers Max voltage: 60V DC Max amps per channel: 75A Cables sold separately The HBL2360 60V 2x75A Brushless DC Motor Controller is a high-current, dual channel controller for hall-sensor equipped Brushless DC motors. The controller uses the position information from the sensors to sequence power on the motors' 3 windings in order to generate smooth continuous rotation. The controller also uses the Hall sensor information to compute speed and measure travelled distance inside a 32-bit counter. The motors may be operated in open or closed loop speed mode. Using low-cost position sensors, they may also be set to operate as heavy-duty position servos. The HBL2360 accepts commands received from an RC radio, Analog Joystick, wireless modem, or microcomputer. For mobile robot applications, the controller's two motor channels can either be operated independently or mixed to set the direction and rotation of a vehicle by coordinating the motion of each motor. Features CAN bus interface up to 1Mbit/s Operates from a single power source USB, RS232, 0-5V Analog, or Pulse (RC radio) command modes Trapezoidal switching based on Hall Sensor position information Built-in programming language for automation and customization Built-in dual 3-phase high-power drivers for two brushless DC motor at up to 75A Auto switch between USB, RS232, Analog, or Pulse based on user-defined priority Specifications Power Motor type: Brushless DC Max voltage: 60V DC Number of channels: 2 Direction: Forward/Reverse Max amps per channel: 75A Continuous amps per channel: 50A On resistance (mohm): 6 mohm Power connections: wires Commands & feedback Analog: Yes RS232: Yes USB: Yes CANbus: Yes RC pulse: Yes Microbasic scripting: Yes Control loop (ms): 1 Input/Output Max analog inputs: 11 Max digital inputs: 19 Digital outputs: 8 Max pulse inputs: 6 Encoder: Yes Mechanical Cooling: Heatsink extrusion Operating environment: -40° to +85°C Dimensions Size: 228mm x 140mm x 40mm Weight: 1500g Multimedia

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RoboteQ
MPN	HBL2360
Type	RoboteQ
UPC	Does not apply
