Hds242s 3-in-1 Oscilloscope True-rms Multimeter Ch 40mhz Bandwidth For Car Audio

US $181.86

Shenzhen, China
Aug 16th

Open on mobile:
QR code

HDS242S 3-in-1 Handheld Oscilloscope Multimeter CH 40MHz Bandwidth For Car Audio Description HDS242S 3-in-1 Handheld Oscilloscope Multimeter Digital Oscilloscope True-RMS Multimeter 2CH 40MHz Bandwidth 20000 Counts for Car Audio Automotive Electronic Features: Versatile Handheld Test Instrument -- Handheld Oscilloscope Function + Digital Multimeter Function + Waveform Generator, 3-in-1 integrated multifunctional handheld test instrument. One key switch easy to operation, compact size with stand bracket suit for outdoor maintenance, rapod on-site measurement, automobile maintenance, power detection, etc. Ergonomic Design -- 3.5-inch high-resolution, high-contrast color LCD display; High reliability with self-calibration function; SCPI supported through USB Type-C interface you can analyze and print data from the oscilloscope. 2pcs 2200mAh 18650 lithium battery, less then 3W power consumption can work continuously for about 6 hours; Included USB Type-C cable for convenient charging. Digital Oscilloscope Main Function -- 2-channel input, 70MHz bandwidth, 250MSa/s real-time sampling rate, Max 8k record length. Cursor measurement function; Multiple auto measurement functions; XY function; One key auto set function, easy to detect and debug. Digital Handheld Multimeter -- Auto ranging 20000 counts true RMS multimeter with hold function can be used to measure standard voltage, current, resistance, diode, capacitance and continuity test, easy to detect and debug. Max AC 750V, DC 1000V input voltage; Independent input of multimeter and oscilloscope support relative measurement function. Waveform Generator -- Max 25MHz frequency output, 0.1Hz resolution; 14-bit vertical resolution, 125MSa/s high sampling rate; 8K waveform length, Max 5Vpp output amplitude. Output sine, square, ramp, pulse and built-in special waveforms. Specification: Brand: OWON Model: HDS242S Function: Oscilloscope + Multimeter + Waveform Generator Plug: US/EU/UK (optional) Battery: 2 * 2200mAh 18650 Lithium Battery Charging Method: USB Type-C Product Size: 198*96*38mm Product Weight: Approx. 0.6kg (main device, without battery) Oscilloscope Specifications: Bandwidth: 40MHz Bandwidth Limit (typical): 20MHz Channels: 2-CH Oscilloscope + 1-CH Generator Sample Rate: 250MSa/s Record Length: 8K Vertical Resolution: 8 bits Acquisition Model: Normal, Peak detect Display: 3.5-inch LCD Waveform Refresh Rate: 10,000 wfrms/s Input Coupling: DC, AC, and Ground Input Impedance: 1 M±2%, in parallel with 16pF±10pF Probe Attenuation Factors: 1X,10X,100X,1000X Max. input Voltage: 400V (DC+AC, PK-PK, 1M input impedance) (10:1 probe attenuation) Horizontal Scale: 5ns/div - 500s/div, step by 1 - 2 - 5 Vertical Sensitivity: 10mV/div - 10V/div Trigger Type: Edge Trigger Modes: Auto, Normal, single Automatic Measurement: Frequency, Period, Amplitude, Max, Min, Mean, PK-PK Communication Interface: USB Type-C Multimeter (Standard): Max. Resolution: 20,000 counts Testing Mode: Voltage, Current, Resistance, Capacitance, Diode ,and Continuity test Input Impedance: 10M Max Input Voltage: AC 750V, DC 1000V Max Input Current: DC: 10A AC: 10A Diode 0 - 2V Waveform Generator: Channel: 1-CH Vertical Resolution: 14bits Waveform Length: 8K Sampling Rate: 125MSa/s Frequency Output: Sine: 0.1Hz - 25MHz Square: 0.1Hz - 10MHz Ramp: 0.1Hz - 1MHz Pulse: 0.1Hz - 5MHz Arbitrary: 0.1Hz - 5MHz Amplitude Range: 20mVpp-5Vpp Output Impedance: 50 Packing List: 1*Handheld Digital Oscilloscope Multimeter 1*Quick Guide 1*USB Cable 1*Probe Adjust 1*Multimeter 1*Soft Bag 1*Bolt Driver 1*Probe 1*BNC to Alligator Clip On May-18-21 at 03:07:46 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	XJX1338MG-59
Product Weight	Approx. 0.6kg (main device, without battery)
Charging Method	USB Type-C
Brand	OWON
Model	HDS242S
Function	Oscilloscope+Multimeter+Waveform Generator
Battery	2 * 2200mAh 18650 Lithium Battery
Product Size	1989638mm
Country/Region of Manufacture	China
UPC	Does not apply
Plug	US/EU/UK (optional)
