Helvar Imagine 920 Dali Router With Sdim And Dmx

EUR 600.00

Co. Dublin, Dublin, Ireland
Jan 29th

Open on mobile:
QR code

New and unused in original box DALI, S-Dim, DMX Network Router (920) The 920 Imagine Router uses an Ethernet connection (10/100 Mbps) as a network backbone, to combine Digidim/DALI and S-DIM networks seamlessly together. Basic functionality is available ‘out-of-box’ without any programming. Helvar’s Designer software allows for advanced configuration and functional programming of the router. The system provides energy-saving features via presence detection and constant light functionality. Further automation can be achieved through scheduled events. OPC server software enables interfacing to Building Management Systems (BMS). A PC can be connected to the system for diagnostics and logging purposes if required, but all data is stored within the system itself, so there is no need for PC control in daily operation. The elimination of a central controller ensures no single point of failure can cause a total system shutdown. Key Features • Each router supports a total of 128 DALI devices (64 devices on each subnet) • 250 mA power supply for each DALI subnet • Up to 100 routers may be networked together • Up to 12 800 DALI devices (16 000 groups) on a router system • Industry standard protocols (TCP/IP and DALI) • Built-in real-time clock • Universal supply input • Up to 252 S-DIM addresses • Up to 512 DMX addresses ‘In’ or ‘Out’ Technical Data Connections Mains supply: Solid core: up to 4 mm? Stranded: up to 2.5 mm? DALI cable: 0.5 mm? – 1.5 mm? (max. 300 m @ 1.5 mm? Override (OVR): Source: 3 V, 50 mA / Sink: Max. 28 V, 50 mA S-DIM/DMX: Low-loss RS485 Type (multistranded, twisted and shielded), 3 or 4 cores + screen 0.22 mm? – 1.5 mm?, max. length 1000 mm Ethernet: 1 x RJ45 10/100 Mbps, Cat 5E up to 100 m (Auto MDI/MDI-X crossover) Power supply Mains supply voltage: 85 VAC – 264 VAC, 45 Hz – 65 Hz Power consumption: 23 VA Power circuit protection: 6 A MCB maximum. The external supply must be protected. Earth – mandatory Supply DALI: 2 mA x 250 mA (current limited) Mechanical data Dimensions: 9U – 160 mm x 58 mm x 100 mm Weight: 260 g Mounting: DIN Rail: keep mains and DALI wiring separate from Ethernet, Override, S-DIM and DMX cables IP code: IP30 (IP00 at connectors) Operating and storage conditions Ambient temperature: 0 °C to 40 °C Relative humidity: Max. 90 %, non-condensing Storage temperature: –10 °C to 70 °C Conformity and standards Emission: EN 55015 Immunity: EN 61547 Safety: EN 60950 DALI data transfer: DALI standard IEC 62386, with Helvar extensions Isolation: 4 kV Environment: Complies with WEEE and RoHS directives

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	HELVAR
Country/Region of Manufacture	United Kingdom
MPN	920
