Hi-accuracy 0.05% Thermocouple Calibrator Output R S B E K J T N & Dc -10mv-1.1v

US $175.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Note: we'll ship this item via Epacket to US, usually the delivery time is about 3 weeks; For other countries, we'll ship it via registered air mail of Post, usually the delivery time is about 40-50 days. If you want express mail service, please contact us for extra postage in advance. Features: 1. The basic accuracy for measurement and output is 0.05%, display 5 digits. 2. Measurement function: DC voltage, thermocouple. 3. Output function: DC voltage, thermocouple. 4. 8 thermocouple types. 5. Auto cool-end compensation when output thermocouple. 6. C or F display. 7. 9V battery (not included), battery life is about 25 hours 8. Operation temperature: 0-50C; Humidity<=80%RH 9. Storage temperature: -10C to 55C; Humidity<=90%RH 9. Size: about 200x100x40mm 10. Weight: 550g 11. Accessories: test leads, PDF manual Specifications: Output Range Output range Resolution Accuracy Voltage 100mV -10.00 ~110.00mV 0.01mV ±0.05% Setting value +30uV The max. output current ±5mA 1000mV -100.00~1100.0mV 0.1mV ±0.05% Setting value ±0.3mV Thermocouple R -40~1760°C 1°C ±0.05% Setting value ±3°C (100°C) standard (Note 1) B 400~1800°C 1°C ±0.05% Setting value ±3°C (400~600°C) ±0.05% Setting value ±2°C (>600°C) E -200.0~1000.0°C 0.1°C ±0.05% Setting value ±2°C (-100°C) Measurement Range Output range Resolution Accuracy Voltage 100mV -10.00 ~110.00mV 10uV ±0.05% Measuring value ±30uV Input Resistance 1M? Thermocouple R -40~1760°C 1°C ±0.05% Measuring value ±3°C (100°C) Adopt the ITS-90 B 400~1800°C 1°C ±0.05% Measuring value ±3°C(400~600°C) ±0.05% Setting value ±2°C (>600°C) temperature standard E -200.0~1000.0°C 0.1°C ±0.05% Measuring value (Note 3) ±2°C (-100°C) Note: 1. Not including the accuracy of inner temperature compensatory transducer. The range of inner temperature compensatory transducer:-10-50°C, compensatory error

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	VC02
Country/Region of Manufacture	China
MPN	VC02
